8 inch lcd panel B080EAN01.1MIPI DSI interface 800*1280 resolution controller board for medical
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B080EAB02.X |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B080EAN01.1 | Diagonal Size: | 8.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×1280 [WXGA] 188PPI | Active Area: | 107.64 × 172.224 Mm (H×V) |
| Outline(mm): | 114.6 × 184.6 × 3.85 (H×V×D) Mm | Luminance: | 400 Cd/m² (Typ.) |
| Contrast Ratio: | 1000:1 (Typ.) (Transmission) | Response: | 30 (Typ.)(Tr+Td) Ms |
| Mass: | 97.0g (Max.) | Used For: | Pad & Tablet |
Product Description
8 inch lcd panel B080EAN01.1MIPI DSI interface 800*1280 resolution controller board for medical
B080EAN01.1 Product details :
| AUO LCD SCREEN B080EAN01.1 | |
| Panel Brand | AUO |
| Model Name | B080EAN01.1 |
| Diagonal Size | 8.0 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 800(RGB)×1280 WXGA 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 107.64 × 172.224 (H×V) mm |
| Outline Size | 114.6 × 184.6 × 3.85 (H×V×D) mm |
| Surface | Glare (Haze 0%) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast | 1000: 1 (Typ.) (transmission) |
| Best angle | Full view |
| Display Mode | AHVA, normally black display, transmissiv |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Number of | 16.7M, 58% NTSC |
| Backlight type | 4S5P WLED, 15K hours, without driver |
| Screen weight | 97.0g (Max.) |
| Apply to | Pad & Tablet |
| Refresh rate | 60Hz |
| Touch function | Without |
| Signal Interface | MIPI (4 data lanes), FPC, 36 pins |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -30 ~ 70 °C Working temperature: -20 ~ 60 °C |
| 8 inch lcd panel B080EAN01.1MIPI DSI interface 800*1280 resolution controller board for medical | |
B080EAN01.1 Description:
1.Highest quality touch LCD screen replacement parts.
2.Reasonable and competitive price.
3.It is used to repair faulty screen, Touch Screen problems, dead pixels, cracked Touch screens, broken etc.
4.Each assembly is tested before shipping and is 100% working;Quality control: All are tested before delivery,No any Dark Spots,Color Point,Deal Pixels.
5.if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible.
6.Each item has been checked and in good condition before shipping.
7. It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
B080EAN01.1 About Shipping:
Wwe will test them strictly before shipping.
We will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
B080EAN01.1 Return and feedback:
All returns must be informed before returning.
The Buyer is ought to notify the seller of all returned items within 7 days after receiving the package. We reserve the right refusing any requirement that informs the seller longer than 7 days.
Exchange due to buyer wrong part ordered, buyer needs to pay 2-ways shipping fee.
Return items must have all original packaging and in good condition.
Return postage and insurance charge is non-refundable for refund or new shipment.
Shipping fees are non-refundable.
B080EAN01.1 FAQ:
Q: How long will I receive my goods B080EAN01.1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of B080EAN01.1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of B080EAN01.1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90days warranty .
B080EAN01.1 Shippment & Packing
