Lumineq EL640.480-AG1 AG 8.1 Inch 640*480 LCD Display Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Lumineq |
| Model Number: | EL640.480-AG1 AG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | EL640.480-AG1 AG | Diagonal Size: | 8.1" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 98PPI | Active Area: | 165.1(W)×123.8(H) Mm |
| Outline(mm): | 218.4 × 155.8 (H×V×D) | Luminance: | 55 Cd/m² (Typ.) |
| Contrast Ratio: | 30 : 1 (Typ.) (TM) | Response: | 1 (Max.) Ms |
| Mass: | 450g | Used For: | Industrial |
Product Description
Lumineq EL640.480-AG1 AG 8.1 Inch 640*480 LCD Display Screen Panel
EL640.480-AG1 AG Product details :
| Lumineq LCD Screen EL640.480-AG1 AG | |
|---|---|
| Brand | Lumineq |
| Model P/N | EL640.480-AG1 AG |
| Diagonal Size | 8.1" |
| Panel Type | EL, EL |
| Resolution | 640×480, VGA 98PPI |
| Pixel Format | Rectangle |
| Active Area | 165.1(W)×123.8(H) mm |
| Outline(mm) | 218.4 × 155.8 (H×V×D) |
| Luminance | 55 cd/m² (Typ.) |
| Contrast Ratio | 30 : 1 (Typ.) (TM) |
| Response | 1 (Max.) ms |
| Color Depth | Monochrome |
| Backlight | self , 30K hours |
| Mass | 450g |
| Used for | Industrial |
| Refresh Rate | 120Hz |
| Touchscreen | Without |
| Signal Type | Parallel Data (1ch, 4-bit) , 20 pins Connector |
| Voltage Supply | 5/12V (Typ.)(VL/VH) |
| Max. Ratings | Storage Temp.: -40 ~ 75 °C Operating Temp.: -5 ~ 55 °C |
| Lumineq EL640.480-AG1 AG 8.1 Inch 640*480 LCD Display Screen Panel | |
EL640.480-AG1 AG Payment :
1.We will send out the order within 1-3 days after confirming the payment.
2.You can choose DHL/TNT for fast shipping
3.We 100% tested one by one before shipping .If the product is faulty during shipping, please inform us immediately after your received it.
EL640.480-AG1 AG Shippment & Packing
EL640.480-AG1 AG Shipping:
We Ship to Worldwide via DHL, UPS, FEDEX, TNT, CPAM, we also have our own cargo to ship the goods worldwise with cheaper price.
Items are shipped via DHL, UPS, FEDEX, TNT, reach most of the countryes whith in 5-15 business days.
Items are shipped from China using Airmail, reach most of the countries within 10 to 40 business days.
EL640.480-AG1 AG Return:
Customer has 7 days to inspect/install the product upon delivery. Please report any damage or dead-on-arrial (DOA) during the period.
Customer may exchange for same exact product within 90-day, when it is determined defects. When exchanging for a different product, customer is considered to conduct two separate transactions, a return and a purchase.
EL640.480-AG1 AG Contract Us:
If you have any question, please contact us by Ali message or contact us by live chat.
EL640.480-AG1 AG FAQ:
Q: Do you accept sample orders of EL640.480-AG1 AG ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of EL640.480-AG1 AG ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods EL640.480-AG1 AG ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of EL640.480-AG1 AG via credit card ?
A: Yes!you can use your credit card through your Paypal account.
