7inch LCM 800*1280 31pins B070EAN01.6 LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B070EAN01.6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B070EAN01.6 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×1280 WXGA 215PPI | Display Size: | 94.2(W)×150.72(H) Mm |
| Outline Size: | 104.32(W)×161.67(H)×4.05(D) Mm | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Screen Weight: | 85.0g (Max.) | Used For: | Pad & Tablet |
Product Description
7inch LCM 800*1280 31pins B070EAN01.6 LCD Display
B070EAN01.6 Product details :
| AUO LCD SCREEN B070EAN01.6 | |
| Panel Brand | AUO |
| Model Name | B070EAN01.6 |
| Diagonal Size | 7.0" |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 800(RGB)×1280 WXGA 215PPI |
| Pixel layout | RGB triangle |
| Display size | 94.2(W)×150.72(H) mm |
| Outline Dim. | 104.32(W)×161.67(H)×4.05(D) mm |
| Treatment | Hard coating |
| Luminance | 400 cd/m² (Typ.) |
| Contrast | 800:1 (Typ.) (transmission) |
| Optical mode | AHVA, Normally Black, Transmissive |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Number of color | 16.7M, 60% NTSC |
| Backlight type | WLED [5 strings], no driver |
| Screen weight | 85.0g (Max.) |
| Apply to | Pad & Tablet |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Interface Type | 31 pins MIPI (4 data lanes), connector |
| Supply voltage | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 7inch LCM 800*1280 31pins B070EAN01.6 LCD Display | |
