7inch LCM 600x1024 400 500:1 16.7M WLED MIPI B070ATN02.0 LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B070ATN02.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | B070ATN02.0 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 600(RGB)×1024 [WSVGA] 170PPI | Display Size: | 89.28 × 152.37 Mm (H×V) |
| Outline Size: | 96.98 × 163.82 × 4.25 Mm (H×V×D) | Viewing Angle: | 70/70/60/60 (Typ.)(CR≥10) |
| Screen Weight: | 82.2g (Max.) | Used For: | Pad & Tablet |
Product Description
7inch LCM 600x1024 400 500:1 16.7M WLED MIPI B070ATN02.0 LCD Display
B070ATN02.0 Product details :
| AUO LCD SCREENB070ATN02.0 | |
| Panel Brand | AUO |
| Model Name | B070ATN02.0 |
| Screen size | 7.0" |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 600(RGB)×1024 [WSVGA] 170PPI |
| Pixel Format | RGB Vertical Stripe |
| Display size | 89.28 × 152.37 mm (H×V) |
| Outline Size | 96.98 × 163.82 × 4.25 mm (H×V×D) |
| Brightness | 400 (Typ.) |
| Contrast | 500: 1 (Typ.) [Transmission] |
| Best View on | 12 o'clock |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 70/70/60/60 (Typ.)(CR≥10) |
| Response Time | 8 (Typ.)(Tr+Td) ms |
| Number of | 16.7M, 50% NTSC |
| Backlight type | 3S6P WLED, no driver |
| Screen weight | 82.2g (Max.) |
| Apply to | Pad & Tablet |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Signal Interface | MIPI (4 data lanes), connector, 32 pins |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
| 7inch LCM 600x1024 400 500:1 16.7M WLED MIPI B070ATN02.0 LCD Display | |
B070ATN02.0 Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
B070ATN02.0 Payment and Tax:
1.Alipay is perferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc.Those fees are not covered by either price or shipping charges of product,and are responsibility of recipient.
B070ATN02.0 Shipping:
1.We usually use alibaba standard shipping to transport
2.we will ship by air mail within 1-3 working days after the end of payment.
We ship packages all over the world, please make sure your mailing address is correct.
3.Generally, it is delivered within 15-30 working days. Because our package have been sent to all over the world, some countries may deliver goods later.
B070ATN02.0 Warranty service:
1. All products are guaranteed for 120 days.
2. Defective or damaged products must be returned within 20 days after delivery.
3. Please wait patiently and give us 3 working days to deal with your return after we receive your returned package.
4. All returned freight shall be borne by the buyer.
B070ATN02.0 FAQ:
Q: Can I pay my goods B070ATN02.0 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of B070ATN02.0 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders for B070ATN02.0 ?
A: Of course!sample order is welcome !
Q: How to make payment for B070ATN02.0 ?
A: We accept T/T , Paypal , western union .
B070ATN02.0 Shippment & Packing
