The 8.0 inch 1024(RGB)*600 LCD Screen Display New original HSD080IFW1-A10
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD080IFW1-A10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD080IFW1-A10 | Diagonal Size: | 8.0" |
|---|---|---|---|
| Resolution: | 1024(RGB)×600, WSVGA 148PPI | Active Area: | 176.64(W)×99.36(H) Mm |
| Bezel Opening: | 180.1(W)×103.4(H) Mm | Outline Size: | 192.8(W)×116.9(H) ×5.2(D) Mm |
| Weight: | 181g (Typ.) | Application: | Automotive Display |
Product Description
The 8.0 inch 1024(RGB)*600 LCD Screen Display New original HSD080IFW1-A10
HSD080IFW1-A10 Product details :
| HannStar LCD Screen HSD080IFW1-A10 | |
|---|---|
| Brand | HannStar |
| Model P/N | HSD080IFW1-A10 |
| Diagonal Size | 8.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 148PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 176.64(W)×99.36(H) mm |
| Bezel Opening | 180.1(W)×103.4(H) mm |
| Outline Dim. | 192.8(H)×116.9(V)×5.2(D) mm |
| Treatment | Hard coating |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/70/75 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.7M 50% NTSC |
| Light Source | WLED , 12K hours , W/O Driver |
| Weight | 181g (Typ.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| Power Supply | 3.3/11.0/18.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| The 8.0 inch 1024(RGB)*600 LCD Screen Display New original HSD080IFW1-A10 | |
HSD080IFW1-A10 SPECIFICATION:
* We apply comprehensive quality check and testing before dispatching
* This item could be used to replace touch panel which is broken, damaged, cracked or unusable.
HSD080IFW1-A10 Payment information:
Please place an order directly.
Other payment methods, such as PayPal, T-T, etc., please contact me.
HSD080IFW1-A10 Shipping and Package :
HSD080IFW1-A10 Replacement/Exchange:
- Exchange/replace item within 30 days from the day you receive the item.
- Buyer will pay for the shipping cost if there is a return or exchange .
- The item that the buyer requires exchange/replacement should be in the same condiction that we dispatched.
HSD080IFW1-A10 CONTACT US:
Please contact us for any question or problem that you may have
(Mon-Sat):
Berlin: 02:00-12:00 | Moscow: 04:00-14:00
Sydney: 11:00-21:00 | New York: 20:00-08:00
HSD080IFW1-A10 FAQ:
Q: If I order HSD080IFW1-A10 now,when will you ship the goods ?
A: The order will be shipped within 1-2 working days after received your payment.
Q: Can you give me a discount if I need a large quantity of HannStar HSD080IFW1-A10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: Can You declare my order of lcd display panel HSD080IFW1-A10 at a very low value ?
A: Yes , we can . pls inform us before shipping .
