OrIginal 21.5 Inch BOE LCD Module MV215FHM-N60 1920*1080 30pin LVDS Desktop LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | MV215FHM-N60 |
| Document: | MV215FHM-N60.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | MV215FHM-N60 | Diagonal Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 476.064(W)×267.786(H) Mm |
| Outline(mm): | 495.6 × 292.2 × 11.2 (H×V×D) | Work Mode: | ADS, Normally Black, Transmissive |
| Mass: | 1.97Kgs (Typ.) | Used For: | Desktop Monitor / Industrial |
| Highlight: | 21.5 inch BOE LCD Module,BOE LCD Module MV215FHM-N60,LVDS Desktop LCD Panel |
||
Product Description
OrIginal BOE 21.5 inch Lcd Module MV215FHM-N60 Desktop 1920*1080 30pin Lvds Screen Lcd Panel
MV215FHM-N60 Product details :
| BOE LCD SCREEN MV215FHM-N60 | |
|---|---|
| manufacturer | BOE |
| Model Name | MV215FHM-N60 |
| screen size | 21.5 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 476.064(W)×267.786(H) mm |
| physical dimension | 495.6(W)×292.2(H) ×11.2(D) mm |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | ADS, Normally Black, Transmissive |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Responding time | 14 (Typ.)(G to G) |
| Number of color | 262K 45% NTSC |
| Backlight type | 16S4P WLED , 30K hours , Without Driver |
| Weight | 1.97Kgs (Typ.) |
| Apply to | Desktop Monitor / Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum rating | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| OrIginal BOE 21.5 inch Lcd Module MV215FHM-N60 Desktop 1920*1080 30pin Lvds Screen Lcd Panel | |
MV215FHM-N60 Attention:
We will send the compatible one instead if the original one out of stock. If you can't accept it, please don't make the order. Thanks for your understanding!
MV215FHM-N60 Note:
Before you ordered, in case of any mistake & trouble in our business, please contact us as below information for double confirming to win this deal together.
MV215FHM-N60 Paymentand Tax:
1.Alipay is preferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc. These fees are not couvered by either price or shipping charges of product and are responsibility of recipient.
3.The order will be cancelled beyond 7 business days on unpaid station.
MV215FHM-N60 Shipping and Package :
MV215FHM-N60 Shipping information:
We will deliver the goods within 1-5 working days after payment settlement.
We provide some goods delivered by Hongkong / China Post free of charge. If you need it urgently, please contact me.
The standard mode of transportation is international air mail. The project will take 7-14 hours to ship from Hong Kong Reception days in most areas (2-3 weeks).
If you do not receive the item within 30 working days (5 weeks), please contact us to investigate the case( Brazil). Italy. 5-8 weeks)
MV215FHM-N60 The delivery time is approximately:
US/UK/Australia 7-14 working days.
Canada 7-25 working days.
It may take 7-20 working days for France/Spain/Germany.
Eastern Europe can take up to 16-30 working days.
It may take up to 30-50 working days for Italy/Brazil/South America.
Shipped by DHL Express (it takes 3-6 working days to arrive)
MV215FHM-N60 FAQ:
Q: How to make payment for MV215FHM-N60 ?
A: We accept T/T , Paypal , western union .
Q: Can You declare my order of MV215FHM-N60 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of MV215FHM-N60 ?
A: 90days warranty .
Q: Can I pay my goods MV215FHM-N60 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
