10.3 inch 1280x480 HSD103IPW1-A10 LCD Monitors Touch Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD103IPW1-A10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | HSD103IPW1-A10 | Diagonal Size: | 10.3" |
|---|---|---|---|
| Resolution: | 1280(RGB)×480, DVGA 133PPI | Active Area: | 243.84(W)×91.44(H) Mm |
| Bezel Opening: | 246.84(W)×94.44(H) Mm | Outline Dim.: | 265.2(H)×109.85(V) ×8.65(D) Mm |
| Weight: | 290g (Typ.) | Designed For: | Automotive Display |
Product Description
10.3 inch 1280x480 HSD103IPW1-A10 LCD Monitors Touch Screen Display
HSD103IPW1-A10 Product details :
| HannStar LCD Screen HSD103IPW1-A10 | |
|---|---|
| Brand | HannStar |
| Model P/N | HSD103IPW1-A10 |
| Diagonal Size | 10.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×480, DVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 243.84(W)×91.44(H) mm |
| Bezel Opening | 246.84(W)×94.44(H) mm |
| Outline Dim. | 265.2(H)×109.85(V) ×8.65(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Support Color | 262K/16.7M 70% NTSC |
| Light Source | WLED [8S3P] , 30K hours , W/O Driver |
| Weight | 290g (Typ.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| Power Supply | 3.3/12.4/20/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 10.3 inch 1280x480 HSD103IPW1-A10 LCD Monitors Touch Screen Display | |
HSD103IPW1-A10 We Promise to:
1:Manufacture only the best consumer goods and ensure the highest quality possible.
2:Deliver goods to our customers all over the world with speed and precision
HSD103IPW1-A10 Terms of Service:
Thank you for reviewing the important information, I will tell you the important steps:
NO:1
The screen of the machine is inside the device, you need to disassemble the machine, and then send me the screen picture (this is very important, please pay attention),And tell me the length, width, and thickness of the screen.
NO:2
Could you please tell me if the display screen is not good, or the touch handwriting is not good, I will confirm the screen information
HSD103IPW1-A10 Shipping and Package :
HSD103IPW1-A10 Shippment:
Usually we will prepare and ship your goods within 1 working day.
Pls check if your item is in good condition upon receipt of it.
HSD103IPW1-A10 Delivery time:
----Via Express: Generally 7-10 working days.
----Via Air Mail: Generally 30-50working days.
HSD103IPW1-A10 Service hours:
If you have any question, please contact us I will sincerely for your service, ourservice time for the Beijing time:8:00-12:00; 1:30-6:00;But we have 24 hourswill have customer service for you to solve the problem.
HSD103IPW1-A10 FAQ:
Q: Can I pay my order of HSD103IPW1-A10 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of HSD103IPW1-A10 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of HSD103IPW1-A10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods HSD103IPW1-A10 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
