TIANMA TM070RFKP01 7.0 inch 800*480 tft lcd display panel screen
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM070RFKP01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | TM070RFKP01 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 133PPI | Pixel Format: | RGB Vertical Stripe |
| Active Area: | 152.4(W)×91.44(H) Mm | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Support Color: | 262K/16.7M 70% NTSC | Designed For: | Automotive Display |
| Frame Rate: | 60Hz | Interface Type: | LVDS (1 Ch, 6/8-bit) + SPI , 30 Pins FPC |
Product Description
TIANMA TM070RFKP01 7.0 inch 800*480 tft lcd display panel screen
TM070RFKP01 Product details :
| Brand | TIANMA |
| Model P/N | TM070RFKP01 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, CELL , FOG |
| Resolution | 800(RGB)×480, WVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | - |
| Outline Dim. | 160.8(W)×101.1(H)×1.44(D) |
| Treatment | Antiglare (Haze 40%) |
| Luminance | 0 (cd/m²) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Max.)(Tr+Td) ms |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | SFT, Normally Black, Transmissive |
| Support Color | 262K/16.7M 70% NTSC |
| Transmittance | 3.8% (Typ.)(with Polarizer) |
| Support Color | 262K/16.7M 70% NTSC |
| Light Source | No B/L |
| Weight | 48.5±2.43g |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) + SPI , 30 pins FPC |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
TM070RFKP01 NOTE:
We are professional in touch screen digitizer of tablet ,GPS displayer ,LCD display & smartphone parts .We mainly do wholesale business ,so if you need more other goods, please contact us for wholesale price .Since some items don't display yet on time,if you need any items ,just send message or contact us!!
TM070RFKP01 Shipping and Package :
TM070RFKP01 Shipment:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 3 days once your payment is completed.We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected.
TM070RFKP01 Warm Tip:
Because China POST AIR MAIL is safety performance low and long time for delivery.If your package is over 200usd or need it urgently, please don't choose the SG post and China Post. Please contact us if you think the shipping cost is wrong.
TM070RFKP01 Warranty & Maintenance:
We offer the 1month free replacement. Buyers may request for a replacement within 15 days from your receipt of the product. The buyer should return the product in the original conditions to us and should bear the shipping costs for return.We also provide 12monthfree maintenance. The buyer should return the product in the original conditions to us and should bear the shipping costs for return. If any part is required to be replaced, the buyer should also pay for the costs of the parts to be replaced.Before returning the items, please confirm the return address and the logistics method with us. After you give the items to the logistic company, please send us the tracking number. As soon as we receive the items, we will repair or exchange them ASAP.
TM070RFKP01 FAQ:
Q: Do you accept sample orders of TM070RFKP01 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of TM070RFKP01 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of TM070RFKP01 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of TM070RFKP01 ?
A: Of course!sample order is welcome !
