15.3 inch 1280*768 NL12876BC26-33NA lcd screen in stock
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL12876BC26-33NA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | NL12876BC26-33NA | Diagonal Size: | 15.3" |
|---|---|---|---|
| Resolution: | 1280(RGB)×768, WXGA 97PPI | Active Area: | 334.08(W)×200.45(H) Mm |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) | Response: | 14/11 (Typ.)(Tr/Td) |
| Work Mode: | SA-SFT, Normally Black, Transmissive | Used For: | Industrial |
| Touch Screen: | PCAP, Optical Bonding | Signal Interface: | LVDS (1 Ch, 6/8-bit), 20 PinsConnector |
Product Description
15.3 inch 1280*768 NL12876BC26-33NA lcd screen in stock
NL12876BC26-33NA Product details :
| Brand | NEC |
| Model P/N | NL12876BC26-33NA |
| Diagonal Size | 15.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×768, WXGA 97PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 334.08(W)×200.45(H) mm |
| Bezel Opening | 336.2(W)×202.8(H) mm |
| Outline Size | 358(W)×251.4(H)×17.3(D) mm |
| Brightness | 470 cd/m² (Typ.) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K/16.7M 40%NTSC |
| Frequency | 60Hz |
| Weight | 1.59/1.76Kgs (Typ./Max.) |
| Surface | Clear, Hard coating (6H) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Display Mode | SA-SFT, Normally Black, Transmissive |
| Response Time | 14/11 (Typ.)(Tr/Td) |
| Lamp Type | 4 strings WLED , 70K hours , Without Driver |
| Touch Screen | PCAP, Optical Bonding |
| Application | Industrial |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pinsConnector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -20 ~ 80 °C |
