15.6 inch 40 pin TFT-LCD 1920*1080 LM156LFGL03 LCD Screen Display For Lenovo Legion 5 120hz monitor
Product Details:
| Place of Origin: | China |
| Brand Name: | PANDA |
| Model Number: | LM156LFGL03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | LM156LFGL03 | Diagonal Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 141PPI | Active Area: | 344.16(W)×193.59(H) Mm |
| Outline Size: | 350.66(W)×216.245(H)×3.2(D) Mm | Luminance: | 250 Cd/m² (Typ.) |
| Outline Shape: | Slim (PCBA Flat, T≤3.2mm) | Used For: | Laptop / Gaming |
| High Light: | LCD Screen Panel,Laptop LCD Screen Assembly,Laptop LCD Screen Display |
||
Product Description
15.6 inch 40 pin TFT-LCD 1920*1080 LM156LFGL03 LCD Screen Display For Lenovo Legion 5 120hz monitor
LM156LFGL03 Product details :
| PANDA LCD Screen LM156LFGL03 (NCP0036) | |
|---|---|
| Panel Brand | PANDA |
| Panel Model | LM156LFGL03 (NCP0036) |
| Panel Size | 15.6" |
| Panel Type | Oxide TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.16(W)×193.59(H) mm |
| Outline Size | 350.66(W)×216.245(H)×3.2(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 45% NTSC |
| Lamp Type | WLED , 15K hours , With LED Driver |
| Frequency | 120Hz |
| Touch Screen | Without |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Application | Laptop / Gaming |
| Signal Interface | eDP (4 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| 15.6 inch 40 pin TFT-LCD 1920*1080 LM156LFGL03 LCD Screen Display For Lenovo Legion 5 120hz monitor | |
LM156LFGL03 NOTE:
1.Before you place your order, if you are not sure which screen model you need, please be sure to contact customer service and we will get back to you promptly.
2.We may ship a compatible screen model according to the inventory. If you need to specify the model, please leave a message or contact customer service.
LM156LFGL03 Payment and Taxes:
1. We recommend Alipay to be safer.
2. Shipment of the products outside China will incur import duties and other charges which are not included in the price or freight of the products and are for the responsibility of the recipient.
LM156LFGL03 Shipping and Package :
LM156LFGL03 About transportation:
1: The recipient must be the company's full name or full name.
2: If the product ordered is very expensive, you need to get the packaging quickly. It is recommended to use DHL or EMS for transportation.
3: If you choose DHL shipping. Some DHL remote addresses require an additional remote address service fee, approximately $ 35. In some countries, aircraft cannot carry spare batteries. Some motherboards do not have a BIOS battery. You can use the original BIOS battery. I hope you can understand.
4: If a customs clearance fee is incurred, the buyer bears it.
5: After receiving the package, please check the package in time. If the packaging is damaged, save the video evidence. We can ask the logistics company to make up.
LM156LFGL03 Return:
Customer has 7 days to inspect/install the product upon delivery. Please report any damage or dead-on-arrial (DOA) during the period.
Customer may exchange for same exact product within 90-day, when it is determined defects. When exchanging for a different product, customer is considered to conduct two separate transactions, a return and a purchase.
LM156LFGL03 FAQ:
Q: If I place order now,when will you ship the goods of LM156LFGL03 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of LM156LFGL03 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods LM156LFGL03 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of LM156LFGL03 ?
A: Of course!If you make a large order, we will give you a discount.
