ZE156IA-01B LCD Screen 15.6 Inch TFT 1920*1080 30 Pins Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | A035VL01 V3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | A035VL01 V3 | Diagonal Size: | 15.6" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, FOB | Resolution: | 1920(RGB)×1080, FHD 141PPI |
| Active Area: | 344.16(W)×193.59(H) Mm | Outline Dim.: | 348.86(W)×203.02(H)×0.87(D) Mm |
| Designed For: | Laptop | View Direction: | Symmetry |
| Response Time: | 25 (Typ.)(Tr+Td) | Transmittance: | 4.39% (Typ.)(with Polarizer) |
| Highlight: | 268PPI Camera LCD Screen,A035VL01 V3 Camera LCD Screen,LTPS TFT LCD Screen |
||
Product Description
ZE156IA-01B LCD Screen 15.6 Inch TFT 1920*1080 30 Pins Connector
ZE156IA-01B Product details :
| Brand | Innolux |
| Model P/N | ZE156IA-01B |
| Diagonal Size | 15.6" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 344.16(W)×193.59(H) mm |
| Bezel Opening | - |
| Outline Dim. | 348.86(W)×203.02(H)×0.87(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Plate Thickness | - |
| Transmittance | 4.39% (Typ.)(with Polarizer) |
| Support Color | 16.7M 69%NTSC |
| Light Source | No B/L |
| Form Style | - |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (2 Lanes), eDP1.2, 30 pinsConnector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
