F062A06-6T2 6.2 inch LCD Screen Display 720*1520 RGB Vertical Stripe
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | F062A06-6T2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | F062A06-6T2 | Diagonal Size: | 6.2" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1520 270PPI |
| Display Size: | 67.608(W)×142.728(H) Mm | Outline Dim.: | 69.6(H)×148.3(V)×0.3(D) Mm |
| Viewing Angle: | 80/80/80/80 (Min.)(CR≥10) | Application: | Mobile Phone |
| View Direction: | Symmetry | Response Time: | 30 (Typ.)(Tr+Td) |
| Highlight: | A035VL01 V0 LCD Screen Display,315 cd/m2 LCD Screen Display |
||
Product Description
F062A06-6T2 6.2 inch LCD Screen Display 720*1520 RGB Vertical Stripe
F062A06-6T2 Product details :
| Brand | Innolux |
| Model P/N | F062A06-6T2 |
| Diagonal Size | 6.2" |
| Panel Type | a-Si TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1520 270PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 67.608(W)×142.728(H) mm |
| Bezel Opening | - |
| Outline Dim. | 69.6(H)×148.3(V)×0.3(D) mm |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Plate Thickness | 0.15+0.15 mm |
| Transmittance | 3.29% (Typ.) |
| Support Color | 16.7M 69%NTSC |
| Light Source | No B/L |
| Weight | 94.4±9.0g |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | In-Cell Touch, I²C |
| D-IC Detail | COG Suggest NT36525 |
F062A06-6T2 About Our:
Our shop has been engaged in physical store wholesale and online retail wholesale in the LCD screen industry for 12 years.
There are many models to choose from and will be uploaded one after another. If you need any screen, you can leave me a message.
F062A06-6T2 Payment:
1.We can accept T/T and Western Union and Money order, the best way is direct order payment .you can choose your convenient payment terms. If you want other payment terms, please let us know before you order.
2.Full payment must be made within 7 days after placing your order, or the order will be invalid or cancelled by the system.
3.Make sure that you have completed all the detailed information like contact person, address, post code and telephone number when filling in your buyer’s information.
F062A06-6T2 Shipping:
All items will be shipped within 48 business hours upon receipt of payment (Except Saturdays and Sundays and holidays).
7-15 working days to USA,Ship by USPS with track number.
14-22 business days to UK Australia,Canada.
18-25 business days to Greece,Spain,Poland,Norway.
18-25 business days to Germany,Filand.Sweden,Malta.
20-25 business days to France, Czech. most of Europe.
30-40 business days to other countries(Brazil and Russia).
This is the normally around ship time.if your country strict customs and will cause delay.
We are not responsible for any custom delay or tax. Import taxes are not included in the item price or shipping fee.
F062A06-6T2 Return & Warranty:
- If the product is defective or not working, please contact us immediately after receiving the product.We offer a 30days Money back or replacement.
- If prove that this product is defective or not working,Please return the product,We will resend a product for you.
- The returned item and all accessories must be in the original (unused) condition. Each item is pasted with a warranty label, please do not tear up the label.
F062A06-6T2 FAQ:
Q: How to order lcd screen F062A06-6T2 ?
A: We accept the T/T , Western union , paypal .
Q: what's the warranty of F062A06-6T2 ?
A: 90 days.
Q: What happen if the F062A06-6T2 I received can't work ?
A: Our lcd panel F062A06-6T2 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: Can you declared low price of my F062A06-6T2 lcd display when shipping?
A: Yes , please inform us the value you want .
F062A06-6T2 Shipping and Package :
