5.7 Inch 320*240 STN LCD Screen DMF-50174ZNB-FW LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | OPTREX |
| Model Number: | DMF-50174ZNB-FW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | DMF-50174ZNB-FW | Diagonal Size: | 5.7" |
|---|---|---|---|
| Panel Type: | STN-LCD, LCM | Resolution: | 320×240, QVGA 70PPI |
| Active Area: | 115.17(W)×86.37(H) Mm | Bezel Opening: | 122.0(W)×92.0(H) Mm |
| Outline Size: | 174(W)×115(H)mm | Application: | Industrial |
| High Light: | 5.7 Inch STN LCD Screen,320*240 STN LCD Screen,STN LCD Display Panel |
||
Product Description
5.7 inch lcd Screen 320*240 STN screen DMF-50174ZNB-FW lcd display panel
DMF-50174ZNB-FW Product details :
| OPTREX LCD DMF-50174ZNB-FW | |
| Panel Brand | OPTREX |
| Panel Model | DMF-50174ZNB-FW |
| Panel Size | 5.7 inches |
| Panel Type | STN-LCD , LCM |
| Resolution | 320×240 QVGA 70PPI |
| Pixel Format | Rectangle |
| Display Area | 115.17(horizontal)×86.37(vertical) mm |
| Bezel Opening | 122.0(horizontal)×92.0(vertical) mm |
| Outline Size | 174(horizontal)×115(vertical) mm |
| Brightness | 50 cd/m² (Typ.) |
| Contrast Ratio | 4:1 (Typ.) (Transmission) |
| Display Mode | STN, blue mode, transmissive |
| Best View on | 6 o'clock |
| Response Time | 100/360 (Typ.)(Tr+Td) ms |
| Display Colors | Monochrome |
| Lamp Type | CCFL [1 pcs] , 15K hours, no driver |
| Frequency | 70Hz |
| Touch Screen | Without |
| Panel Weight | 300g |
| Application | Industrial |
| Signal Interface | 14 pins Parallel Data (4-bit) , terminal |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C |
| 5.7 inch lcd Screen 320*240 STN screen DMF-50174ZNB-FW lcd display panel | |
