DMF-50773NB-FW LCD Display Screen 5.4 Inch 240*128 50PPI Monochrome
Product Details:
| Place of Origin: | China |
| Brand Name: | OPTREX |
| Model Number: | DMF-50773NB-FW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | DMF-50773NB-FW | Diagonal Size: | 5.4" |
|---|---|---|---|
| Resolution: | 240×128 50PPI | Active Area: | 119.97(W)×63.97(H) Mm |
| Bezel Opening: | 126.0(W)×70.0(H) Mm | Outline(mm): | 170 × 105 (H×V×D) |
| Mass: | 250g (Max.) | Used For: | Industrial |
| Highlight: | DMF-50773NB-FW LCD Display Screen,LCD Display Screen 5.4 inch |
||
Product Description
Original in stock DMF-50773NB-FW 5.4 inch 240*128 LCD Display Screen
DMF-50773NB-FW Product details :
| OPTREX LCD DMF-50773NB-FW | |
| Panel Brand | OPTREX |
| Panel Model | DMF-50773NB-FW |
| Panel Size | 5.4 inches |
| Panel Type | STN-LCD, LCM |
| Resolution | 240×128 50PPI |
| Pixel Format | Rectangle |
| Display Area | 119.97(horizontal)×63.97(vertical) mm |
| Bezel Opening | 126.0(horizontal)×70.0(vertical) mm |
| Outline Size | 170(horizontal)×95(vertical) mm |
| Brightness | 100 cd/m² (Typ.) |
| Contrast Ratio | 7:1 (Typ.) (Transmission) |
| Viewing Angle | 50/45/32/48 (Typ.) (CR≥2) |
| Display Mode | STN, black and white mode, transflective |
| Best View on | 6 o'clock |
| Response Time | 150/220 (Typ.)(Tr/Td) ms |
| Display Colors | Monochrome |
| Lamp Type | 1 pcs CCFL , 15K hours, without driver |
| Frequency | 70Hz |
| Touch Screen | Without |
| Panel Weight | 250g (Max.) |
| Designed For | Industrial |
| Signal Interface | 8-bit parallel port, 20 pins |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C |
| DMF-50773NB-FW LCD SCREEN PANEL DISPLAY Replacement | |
DMF-50773NB-FW NOTE:
Be sure to compare your panel with the one shown in the photo - the appearance, fasteners and connector must match.
Pay attention to compatible / incompatible models (if any).
Attention! You will receive one of the compatible models in the delivery, it may not match the one indicated in the header.
In the same Machine panel, there may be different, incompatible matrices.
Installation of the panel requires a high qualification of a specialist.
DMF-50773NB-FW Shipping and Package :
DMF-50773NB-FW About delivery:
1. After placing an order, please check your address and postcode carefully, and remember to write your full name on ALI, which is very important for successful delivery of the package.We will deliver the goods to you as soon as we receive the payment.
2. We will send the package within 1-3 working days after you place the order and pay. If you place the order on weekends or holidays, we will arrange to send the package every two Mondays.
3. If you want to order a large quantity of goods, please contact us to check the stock before payment.It may take us a long time to prepare a large number of orders. We will let you know exactly how long it will take.
4. If you do not receive the product within 45 days, please contact us.Please give 3 working days to check the undelivered package. If it is our problem, we will refund to you. If it is the logistics provider's problem, we will contact the logistics provider to deal with the situation as soon as possible.
5. Occasionally, customs clearance requires payment from the buyer
DMF-50773NB-FW Warranty service:
1.All the products is 90 days warranty.
2.Defective or broken products must be returned within 20 days after delivered.
3.Just please be patient give us 3 working days to process your returned after we received your returned package.
4.All returned shipping cost will be buyer responsibility.
DMF-50773NB-FW Other policies:
If you need a lot of quantity, please contact us, will give you a favorable price.
We are not responsible for all taxes and import duties
Due to the time difference, all emails will be reply within 24 hours. Thank you for your understanding!
DMF-50773NB-FW FAQ:
Q: How to order OPTREX lcd panel DMF-50773NB-FW ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel DMF-50773NB-FW I received can't work ?
A: OPTREX DMF-50773NB-FW will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: What is the different between original lcd panel and compatible lcd display?
A: Function is the same , Of course the original lcd's quality and lifetime better than that compatible lcd .
Q: How to order if I don't know the lcd panel number ?
A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.
