23.0 Inch LCD Display Screen LM230WF4-TLA1 For Desktop Monitor
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LM230WF4-TLA1 |
| Document: | LM230WF4-TLA1.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LM230WF4-TLA1 | Diagonal Size: | 23.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 95PPI | Active Area: | 509.184(W)×286.416(H) Mm |
| Bezel Opening: | 513.784(W)×291.016(H) Mm | Outline Size: | 533.2(W)×312(H)mm |
| Panel Weight: | 2.60/2.73Kgs (Typ./Max.) | Application: | Desktop Monitor |
| Highlight: | 95PPI LCD Display Screen,LM230WF4-TLA1 LCD Display Screen,LVDS 23 inch LCD Panel |
||
Product Description
LM230WF4-TLA1 New and original 23.0 inch LCD Display Screen
LM230WF4-TLA1 Product details :
| LG Display LCD SCREEN LM230WF4-TLA1 | |
| manufacturer | LG Display |
| Model Name | LM230WF4-TLA1 |
| screen size | 23.0 inch |
| Screen type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080 [FHD] 95PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 509.184(H)×286.416(V) mm |
| physical dimension | 533.2(H)×312(V) mm |
| Visual size | 513.784(H)×291.016(V) mm |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Best angle | 6 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 85/85/75/85 (Typ.)(CR≥10) |
| Responding time | 1/4 (Typ.)(Tr/Td); 3 (Typ.)(G to G) |
| Number of color | 16.7M 72% NTSC |
| Backlight type | CCFL [4 pcs] , 50K hours , W/O Driver |
| Weight | 2.60/2.73Kgs (Typ./Max.) |
| Apply to | Desktop Monitor |
| Refresh rate | 120Hz |
| Touch function | No touch |
| signal system | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Supply voltage | 12.0V (Typ.) |
| Maximum rating | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LM230WF4-TLA1 New and original 23.0 inch LCD Display Screen | |
LM230WF4-TLA1 Notice:
1.Before installing the LCD screen, please turn off the power first, unplug the screen cable, and turn on the power after all the installation work is completed.
if your lcd screen are used on D-E-L-L brand laptop, please note when you place order,it is important.
2.All panels will be sent out after strict testing to ensure that you can install them directly after receiving them.all panelsA+ grade no dead pixels
3.Please check the specific information of the Panel, we will ensure that the issued panel is fully compatible, if you are not sure about your specific panel, please send us the panel picture on your current machine to confirm, we will reply you as soon as possible.
4.If you are a professional and know the panel model you need, you can directly place an order to buy.
5.All panel will be packed by antistatic bag and box.
LM230WF4-TLA1 PAYMENT:
After you cancelled the order, money will back to your account within 1-15 business days
LM230WF4-TLA1 Shipping and Package :
LM230WF4-TLA1 SHIPPING:
Please confirm your address before payment.
We will send the items within 24 hours once your payment is completed.(Holidays may be extended)
LM230WF4-TLA1 RETURN POLICY:
Customer should return items in original condition within 3 days if any item is defective upon receipt. Buyeris responsible for return shipping & handling costs.
LM230WF4-TLA1 FAQ:
Q: How to order PANDA LM230WF4-TLA1?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: When will ship my order LM230WF4-TLA1 ?
A: The order are shipped within 1-2 working days after received the payment.
Q: What happen if LM230WF4-TLA1 I received can't work ?
A: PANDA LM230WF4-TLA1 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: How long the warranty of 23.0 inch TFT-LCD LM230WF4-TLA1 ?
A: 90 DAYS.
