Name: LPM060A513A 6.0 inch LCD Screen Display Panel For Mobile Phone
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: LPM060A513A
Availability: InStock

Brand Name:	JDI
Model Number:	LPM060A513A
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LPM060A513A

Diagonal Size:

6.0"

Resolution:

1080(RGB)×2160 403PPI

Active Area:

68.04(W)×136.08(H) Mm

Outline (mm):

69.44(H)×145.28(V) Mm

Luminance:

470 Cd/m² (Typ.)

Response Time:

30 (Typ.)(Tr+Td)

Used For:

Mobile Phone

Viewing Angle:

80/80/80/80 (Min.)(CR≥10)

Operating Mode:

IPS, Normally Black, Transmissive

Supply Ability:

100000 Unit/Units per Month

Highlight:

A035QN03 V1 LCD Screen Display Panel

350 cd/m2 LCD Screen Display Panel

Digital Camera AUO LCD Screen

Product Description

LPM060A513A 6.0 inch LCD Screen Display Panel For Mobile Phone

LPM060A513A Product details :

Brand	JDI
Model P/N	LPM060A513A
Diagonal Size	6.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1080(RGB)×2160 403PPI
Pixel Format	RGB Vertical Stripe
Active Area	68.04(W)×136.08(H) mm
Bezel Opening	-
Outline Dim.	69.44(H)×145.28(V) mm
Treatment	Anti Fingerprint + Clear
Luminance	470 cd/m² (Typ.)
Contrast Ratio	1500:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Typ.)(Tr+Td)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Operating Mode	IPS, Normally Black, Transmissive
Support Color	16.7M 99%DCI-P3
Light Source	WLED [3 strings], W/O Driver
Weight	50.0g (Typ.)
Designed For	Mobile Phone
Frame Rate	60Hz
Touch Panel	PCAP, I²C
Interface Type	MIPI (4 data lanes), 40 pinsConnector
Power Supply	1.8/5.5/5.5V (Typ.)(VDDI/AVDD/AVEE)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C

LPM060A513A Shipment Information:

We can ship to you by DHL / FedEX / TNT / UPS / EMS…

you can choose the shipping method you prefer.

The buyer is responsible for any tax or duty charged by their country.

LPM060A513A ESTIMATED DELIVERY TIME:

- We Would Ship Out your order within 24 hours

- Economy: 15-50 days

- Standard: 10-35 days

- Expedited: 4-7 days

LPM060A513A WARRANTY:

- 100% Tested before shipping

- Exchange/replace item within 90 days,counting from the day you receive merchandise.

- Buyer pay the return shipping cost.

- Exchange/replace item should be new.

LPM060A513A About Shipping:

- Please provide the full name of consignee and detailed address for shipping. Full Tested 100% Working By Real equipment before Shipping.

- All items will be shipped within 48 business hours upon receipt of payment (except Saturday,Sunday and Statutory holidays).

- We are not able to take any responsibility for any custom delay or tax. Import duties, taxes and charges are not included in the item price or shipping charges.

- We strive our best to provide you the most reliable, affordable way of shipping service.But sometimes international delivery is highly depended on the courier company and local customs/duties.

- If you do not receive your item on time, please contact us immediately for further assistance.

LPM060A513A FAQ:

Q: Can you test the lcd panel LPM060A513A before shipping ?

A: Yes , of course , don't worry , our item was tested ok before shipping .

Q: Do you accept the sample order LPM060A513A ?

A: Yes , sample order is welcome.

Q: Can you declared low value of my order LPM060A513A ?

A: Yes , we can , you can tell us before shipping .

Q: How long the warranty of lcd LPM060A513A ?

A: 90 days .

LPM060A513A Shipping and Package :
