7.0 inch LCD screen JJ070IA-18G 800*480 lcd panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | JJ070IA-18G |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | JJ070IA-18G | Diagonal Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 133PPI | Active Area: | 152.4(W)×91.44(H) Mm |
| Outline (mm): | 160.2 × 101.7× 1 (H×V×D) | Luminance: | 0 Cd/m² |
| Response: | 15/10 (Typ.)(Tr/Td) Ms | Used For: | Automotive Display |
| Glass Thickness: | 0.50+0.50 Mm | Transmissivity: | 4.49% (Typ.) |
Product Description
7.0 inch LCD screen JJ070IA-18G 800*480 lcd panel
JJ070IA-18G Product details :
| Brand | Innolux |
| Model P/N | JJ070IA-18G |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 800(RGB)×480, WVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | - |
| Outline(mm) | 160.2 × 101.7× 1 (H×V×D) |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Response | 15/10 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | 4.49% (Typ.) |
| Color Depth | 16.7M 68%NTSC |
| Backlight | No B/L |
| Mass | - |
| Used for | Automotive Display |
| Refresh Rate | - |
| Touchscreen | Without |
| Driver IC list | Suggest COG NT51629 + NT52601 |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
JJ070IA-18G Shipment Information:
We can ship to you by DHL / FedEX / TNT / UPS / EMS…
you can choose the shipping method you prefer.
The buyer is responsible for any tax or duty charged by their country.
JJ070IA-18G ESTIMATED DELIVERY TIME:
- We Would Ship Out your order within 24 hours
- Economy: 15-50 days
- Standard: 10-35 days
- Expedited: 4-7 days
JJ070IA-18G Refund&Replacement:
1. Please contact us within 7 days if you have any question after you receiving the items.
2.The returned items has to be in its original condition, specific reason for the return,
We will issue a return or replacement for your order after we received the returns.
3.The buyer is responsible for all the shipping cost incurred.
JJ070IA-18G FAQ:
Q: When would you ship,IF I order JJ070IA-18G ?
A: The order are shipped within 1-2 working days after received the payment.
Q: How to order JJ070IA-18G ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: Can you test lcd panel JJ070IA-18G before shipping?
A: Don't Worry , The JJ070IA-18G will be tested ok before shipping.
Q: What happen if JJ070IA-18G received can't work ?
A: Our JJ070IA-18G was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
