PANDA 21.5 inch LM215DU1A tft screen lcd display tft lcd screen module tft lcd display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | PANDA |
| Model Number: | LM215DU1A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | LM215DU1A | Diagonal Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 476.64(W)×268.11(H) Mm |
| Bezel Opening: | 479.84(W)×271.3(H) Mm | Outline(mm): | 495.6 × 292.2 × 10.8 (H×V×D) |
| Mass: | 1.62Kgs (Typ.) | Used For: | Desktop Monitor |
Product Description
PANDA 21.5 inch LM215DU1A tft screen lcd display tft lcd screen module tft lcd display panel
LM215DU1A Product details :
| PANDA LCD Screen LM215DU1A | |
| Brand | PANDA |
| Model | LM215DU1A |
| Diagonal Size | 21.5 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 102PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 476.64(H)×268.11(V) mm |
| Outline Dim. | 495.6(H)×292.2(V)×10.8(D) mm |
| Bezel Area | 479.84(H)×271.3(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | VA, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [15S4P] , 30K hours , W/O Driver |
| Weight | 1.62Kgs (Typ.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| PANDA 21.5 inch LM215DU1A tft screen lcd display tft lcd screen module tft lcd display panel | |
LM215DU1A Buyer Notice:
1. We are not responsible for any customs or import duties.
2.We will send the compatible one instead if the original one out of stock.which may not be exactly the same as the model of your original screen or inconsistent with the advertising picture in the product, but we can ensure that it is suitable for 100% model
3.For all the problems, please do not leave negative feedback or open dispute before contacting us, Please send us message via AliExpress and we will solve the problem for you immediatel
4. Product grades are available A+ (perfect) and A- (defective/imperfect) to meet various customer needs.
5. Provide a 90-day warranty time, man-made damage and natural disasters are not covered by the warranty! (calculated from the time the goods arrive at the destination)
LM215DU1A Shipping and Package :
LM215DU1A About the shipping:
The recipient must be full name or company name.We use Aliexpresss standard transport EMS DHL, fedex, etc. You can choose the next order. if you want to quickly get parcel. Recommend the use of DHL or by EMS, if you choose the DHL transport. Some remote address DHL needs additional remote address for service. Fees paid by the buyer. Customs clearance fee, if any, shall be borne by the buyers.
After completion of the payment, the goods will be sent 1-3 working days. (part of the product according to the inventory needs more days)
LM215DU1A About the goods:
Receive delivery company products, please check whether the parcel in good face to face. If damaged packaging or product damage, please refuse and ask the photos to prove it. Photos are divided into two parts, divided into two parts. A customer himself as evidence, the other a Courier company as a third party. Then when we received the Courier company send us the pictures of damaged products, we will find out is responsible for the damage to the product of the case. No third party evidence we can't pay for
LM215DU1A Advantageous Price:
All the quotations are based on prompt market price and large quantity,so you can get best supports and first-hand information.
LM215DU1A FAQ:
Q: How to order lcd panel LM215DU1A ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: When will my order 21.5 inch lcd panel LM215DU1A ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you test 21.5 inch lcd panel LM215DU1A before shipping?
A: Don't Worry , Our PANDA LM215DU1A was tested ok before shipping
Q: What happen if PANDA LM215DU1A I received can't work ?
A: Our PANDA lcd LM215DU1A was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
