LM140LF1L02 14.0 Inch 1920*1080p IPS LCD Display 60hz Monitor 9S5P WLED Backlight
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | LM140LF1L02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LM140LF1L02 (NCP002C) | Screen Size: | 14.0 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 157PPI | Active Area(mm): | 309.312 × 173.988 (H×V) |
| Outline(mm): | 315.81 × 205.1 × 3 (H×V×D) | Backlight: | 9S5P WLED , 15K Hours , With LED Driver |
| Outline Shape: | Slim (PCBA Flat, T≤3.2mm) | Used For: | Laptop |
| Highlight: | LM140LF1L02 IPS LCD Display,9S5P WLED IPS LCD Display,14.0 Inch IPS LCD Display |
||
Product Description
LM140LF1L02 14.0 inch 1920*1080p IPS LCD Display 60hz monitor
LM140LF1L02 (NCP002C) Product details :
| PANDA LCD Screen LM140LF1L02 (NCP002C) | |
| Manufacturer | PANDA |
| Model Name | LM140LF1L02 (NCP002C) |
| Screen Size | 14.0 inch |
| Screen Type | LCM , Oxide TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 157PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 309.312 × 173.988 (H×V) |
| Outline(mm) | 315.81 × 205.1 × 3 (H×V×D) |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 250 (Typ.)(cd/m²) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Work Mode | FFS, Normally Black, Transmissive |
| Good View at | Symmetry |
| Response | 25 (Typ.)(Tr+Td) ms |
| Color Depth | 262K 45% NTSC |
| Backlight | 9S5P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
| LM140LF1L02 14.0 inch 1920*1080p IPS LCD Display 60hz monitor | |
LM140LF1L02 (NCP002C) About the company:
1: Our company specializes in the sale of computer spare parts and 10 years of foreign trade experience. Professional sales of computer peripherals, such as motherboards, graphics cards, monitors, keyboards, etc.
2: We are looking for long-term partners. If you are interested in our products, please contact us. We will provide you with more favorable prices and better warranty policies.
3: If you place an order, please read and accept all the above policies on your behalf. I wish you a happy shopping, thank you very much.
LM140LF1L02 (NCP002C) Attention:
Please check your computer model, resolution and screen specification before placing an order to ensure that our products match your model. If you are not sure what your screen specification is, please contact us in time. We will contact you within 24 hours.
LM140LF1L02 (NCP002C) Shipping and Package :
LM140LF1L02 (NCP002C) Shipping:
1. We use ALI stand to transport EMS DHL FEDEX, etc.
2. we will ship by air mail within 1-2 working days after the end of payment. We ship packages all over the world, please make sure your mailing address is correct.
3. Generally, it is delivered within 15-30 working days. Because our goods are sent to all over the world, some countries may deliver goods later. In this case, we hope the customers understand.
LM140LF1L02 (NCP002C) Return:
1: A full refund will be given if items are returned in their original condition.
2:Merchandise which is damaged or missing components is not refundable.
3: Buyers are responsible for return shipping with proper packaging.
4: Once receiving items, we will refund you immediately.
LM140LF1L02 (NCP002C) FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can you give me a discount if I need a large quantity of LM140LF1L02 (NCP002C) ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I place order now,when will you ship the goods of LM140LF1L02 (NCP002C) ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of LM140LF1L02 (NCP002C) ?
A: Of course!sample order is welcome !
