LM140LF1F02 Laptop LCD Screen FHD IPS 144Hz 1920x1080 72% NTSC LCD Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | LM140LF1F02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LM140LF1F02 (NCP005E) | Diagonal Size: | 14.0 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 [FHD] 157PPI | Active Area: | 309.312(H)×173.988(V) Mm |
| Outline Dim.: | 315.81(H)×197.57(V)×2.4(D) Mm | Treatment: | Antiglare, Hard Coating (3H) |
| Form Style: | Slim (PCBA Flat, T≤3.2mm) | Designed For: | Laptop / Gaming |
| Highlight: | LM140LF1F02 Laptop LCD Screen,144Hz Laptop LCD Screen,FHD IPS Laptop LCD Panel |
||
Product Description
LM140LF1F02 laptop lcd FHD IPS 144Hz 1920x1080 72% NTSC LCD Panel
LM140LF1F02 (NCP005E) Product details :
| PANDA LCD Screen LM140LF1F02 (NCP005E) | |
| Manufacturer | PANDA |
| Model Name | LM140LF1F02 (NCP005E) |
| Screen Size | 14.0 inch |
| Screen Type | LCM , Oxide TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 157PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 309.312 × 173.988 (H×V) |
| Outline(mm) | 315.81 × 197.57 × 2.4 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 300 (Typ.)(cd/m²) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Work Mode | FFS, Normally Black, Transmissive |
| Good View at | Symmetry |
| Response | 25 (Typ.)(Tr+Td) ms |
| Color Depth | 16.7M 72% NTSC |
| Backlight | 9S6P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop / Gaming |
| Refresh Rate | 144Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM140LF1F02 laptop lcd FHD IPS 144Hz 1920x1080 72% NTSC LCD Panel | |
LM140LF1F02 (NCP005E) Store opening!!!
Our shop has been engaged in physical store wholesale and online retail wholesale in the LCD
screen industry for 10 years.
There are many models to choose from and will be uploaded one after another. If you need any screen, you can leave me a message.
1): Project status: The new front screen has the original logo. The logo in the picture has been deleted,After completing the test, complete 100% of the work.
2):For our cooperation, please make sure the comparison product is the same as your laptop screen, please check the screen size, resolution and interface type.
2. Or you can send me your laptop model and screen model (such as "LM140LF1F02") so that we can check it for you as soon as possible. Best to send me a picture of your laptop model and screen.
3. If you want to order a lot of items, we look forward to doing more business with you. We can give you the best price. Please feel free to contact us even if you have any questions. Due to the time difference, we will get back to you within 12 hours.
LM140LF1F02 (NCP005E) Payment:
1: We accept Alipay, PayPal, Western Union, TT here
2: All major credit cards are accepted through secure payment processor ESCROw
3:Please make sure you read the entire description and agree to the transaction before buying.
LM140LF1F02 (NCP005E) Shipping and Package :
LM140LF1F02 (NCP005E) About transportation:
1: The recipient must be the company's full name or full name.
2: If the product ordered is very expensive, you need to get the packaging quickly. It is recommended to use DHL or EMS for transportation.
3: If you choose DHL shipping. Some DHL remote addresses require an additional remote address service fee, approximately $ 35. In some countries, aircraft cannot carry spare batteries. Some motherboards do not have a BIOS battery. You can use the original BIOS battery. I hope you can understand.
4: If a customs clearance fee is incurred, the buyer bears it.
5: After receiving the package, please check the package in time. If the packaging is damaged, save the video evidence. We can ask the logistics company to make up.
LM140LF1F02 (NCP005E) Warranty:
1: we will provide 90 days warranty.
2: Buyers are only responsible for the return shipping fees for warranty items. (In most cases, buyers will only have to return the problem components rather than the entire package.)
3:Before returning items, please make sure you get to our return address, and write“gift”on the delivery sheet. Please use regular
postal service and give us the tracking number. Once we receive the items, we will repair them of exchange them asap.
LM140LF1F02 (NCP005E) FAQ:
Q: How long will I receive my goods LM140LF1F02 (NCP005E) ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of LM140LF1F02 (NCP005E) to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of LM140LF1F02 (NCP005E) via credit card ?
A: Yes!you can use your credit card through your Paypal account.
