PANDA Laptop LCD Screen Display 13.3 Inch RGB 1920×1080 30Pin LM133LF4L01
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | LM133LF4L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LM133LF4L01 | Diagonal Size: | 13.3 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 [FHD] 166PPI | Active Area: | 293.76(H)×165.24(V) Mm |
| Outline Dim.: | 305.2(H)×188.1(V)×2.85(D) Mm | Light Source: | WLED , 10K Hours , With LED Driver |
| Form Style: | Slim (PCBA Flat, T≤3.2mm) | Designed For: | Laptop |
| High Light: | PANDA Laptop LCD Screen Display,Laptop LCD Screen Display LM133LF4L01 |
||
Product Description
PANDA Laptop lcd screen Display 13.3 inch 1920(RGB)×1080 30Pin LM133LF4L01
LM133LF4L01 Product details :
| PANDA LCD Screen LM133LF4L01 | |
| Manufacturer | PANDA |
| Model Name | LM133LF4L01 |
| Screen Size | 13.3 inch |
| Screen Type | LCM , Oxide TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 166PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 293.76 × 165.24 (H×V) |
| Outline(mm) | 305.2 × 193.85 × 3 (H×V×D) |
| Treatment | Antiglare (Haze 24%) |
| Luminance | 250 (Typ.)(cd/m²) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Work Mode | FFS, Normally Black, Transmissive |
| Good View at | Symmetry |
| Response | 25 (Typ.)(Tr+Tf) ms |
| Color Depth | 16.7M 70% NTSC |
| Backlight | WLED , 10K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| PANDA Laptop lcd screen Display 13.3 inch 1920(RGB)×1080 30Pin LM133LF4L01 | |
