21.5 Inch LC215DTBA 1920*1080 LCD Screen Display 30 Pin TFT LCD Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | LC215DTBA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LC215DTBA | Panel Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 102PPI | Display Area: | 476.64(W)×268.11(H) Mm |
| Outline Size: | 487.54(W)×282.91(H)×1.83(D) Mm | Response Time: | 5 (Typ.)(Tr+Td) |
| Weight: | 570g (Typ.) | Application: | Desktop Monitor |
| High Light: | LC215DTBA LCD Screen Display,LVDS LCD Screen Display,30 pin TFT LCD Panel |
||
Product Description
21.5 inch LC215DTBA 1920*1080 lcd screen 30 pin TFT-LCD Panel
LC215DTBA Product details :
| PANDA LCD Screen LC215DTBA | |
| Manufacturer | PANDA |
| Model Name | LC215DTBA |
| Screen Size | 21.5 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 102PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 476.64 × 268.11 (H×V) |
| Outline(mm) | 487.54 × 282.91 × 1.83 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Response | 5 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Glass Thickness | 0.70+0.70 mm |
| Transmissivity | 5.45% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 72% NTSC |
| Backlight | No B/L |
| Mass | 570g (Typ.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Driver IC list | Built-in COF 6 source + 3 gate chips |
| Signal Type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 21.5 inch LC215DTBA 1920*1080 lcd screen 30 pin TFT-LCD Panel | |
LC215DTBA Service:
1.We aim to provide you a pleasing shopping experience and will try our best to meet your requirement. If you satisfy with our products and service, please leave a positive feedback, if you need anything we should do further assistance, please feel free to contact us and give us a opportunity to solve any problem. Thank you for your attention.
2.Customer service will check our orders everyday, when we are online, you will get immediate reply.
3.All pictures are 100% the same as the goods you will receive.
LC215DTBA Shipping and Package :
LC215DTBA Shippment:
The panel will be 100% check and test before shippment.
We will handle your order within 3-5 business day after got your order(Weekends And Holidays Excluded).
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
We also can offer Expedited International Shipping(FedEx,UPS or DHL) with extra fee if you need the item urgently.
Buyer is responsible for customs duty fee.
LC215DTBA Return& Refund:
Please read the item description and check the pictures carefully before bidding.
Refund or Return is available if the item arrived broken,not as described or does not do what it's supposed to.
LC215DTBA WARRANTY:
- Exchange/replace item within 60 days
counting from the day you receive merchandise.
- Buyer pay the return shipping cost.
- Exchange/replace item should be new.
LC215DTBA FAQ:
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of LC215DTBA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for LC215DTBA ?
A: We accept T/T , Paypal , western union .
Q: What happen if the LC215DTBA I receive can't work ?
A: The LC215DTBA will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
