LC185TT7A LCD Monitor Touch Screen Display Replacement RGB 1366×768 WXGA 84PPI
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | LC185TT7A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LC185TT7A | Panel Size: | 18.5" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA, 84PPI | Display Area: | 409.8(W)×230.4(H) Mm |
| Outline Size: | 421.45(W)×242.5(H)×1.43(D) Mm | Driver IC: | COFBuilt-in 4 Source +2 Gate Chips |
| Panel Weight: | 306g (Typ.) | Application: | Desktop Monitor |
| High Light: | LC185TT7A LCD Monitor Touch Screen,WXGA LCD Monitor Touch Screen,84PPI Touch Screen Display Replacement |
||
Product Description
New Original LC185TT7A LCD Monitors Touch Screen Display Replacement
LC185TT7A Product details :
| PANDA LCD Screen LC185TT7A | |
| Panel Brand | PANDA |
| Panel Model | LC185TT7A |
| Panel Size | 18.5" |
| Panel Type | a-Si TFT-LCD, CELL |
| Resolution | 1366(RGB)×768, WXGA, 84PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 409.8(W)×230.4(H) mm |
| Outline Size | 421.45(W)×242.5(H)×1.43(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 5 (Typ.)(Tr+Td) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 6.4% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 73% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 4 source +2 gate chips |
| Panel Weight | 306g (Typ.) |
| Application | Desktop Monitor |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| New Original LC185TT7A LCD Monitors Touch Screen Display Replacement | |
LC185TT7A Helpful Information:
To make sure you purchase a correct screen, please be sure to match size, resolution, and back light of product. If you are uncertain, please contact us with your lcd brand/serial/model, or model number on back of the screen. Our technicians will help you to choose the correct screen.
LC185TT7A Friendly Reminder :
- Installation guide is not included,We are not responsible for any damage caused by the installation of this accessory, make sure you understand how to install before ordering.
- Special skills and techniques required for proper installation. We recommend you process your repairment with an assistance of a qualified technician.
- Please make sure you understand disassembly procedure before purchase.It is strongly recommended that customers test the product before installation.
LC185TT7A Shipping and Package :
LC185TT7A About Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
LC185TT7A Delivery time is approx:
United States / United Kingdom / Australia 7-14 working days.
Canada 7-25 working days.
France / Spain / Germany may take 7-20 working days.
Eastern Europe may take up to 16-30 working days.
Italy / Brazil / South America may take up to 30-50 working days.
Shipped by DHL Express (Need 3-6 working days to arrive)
LC185TT7A Contact Us:
- If you haven't received your goods over 45days(Except Christmas and New year day). Please contact me immediately.
- Resend or a full refund will be issued to you without any excuse
If you need a lot of products, please contact us first.
LC185TT7A FAQ:
Q: How long will I receive my goods LC185TT7A ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: If I place order now,when will you ship the goods of LC185TT7A ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of LC185TT7A via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
