AUO Vertical Stripe 15.6 Inch LCD Panel B156HAN06.1 HW2B 1920*1080 30 Pins
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | B156HAN06.1 HW2B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | B156HAN06.1 HW2B | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 FHD 141PPI | Active Area: | 344.16(H)×193.59(V) Mm |
| Outline Dim.: | 359.5(H)×223.8(V) ×3.2(D) Mm | Viewing Angle: | 85/85/85/85 (Typ.) (CR≥10) |
| Display Colors: | 262K , 45% NTSC | Designed For: | Laptop |
| High Light: | AUO 15.6 Inch LCD Panel,30 pins 15.6 Inch LCD Panel,B156HAN06.1 HW2B |
||
Product Description
AUO Vertical Stripe 15.6 Inch LCD Pane B156HAN06.1 HW2B 1920*1080 30 pins
B156HAN06.1 HW2B Product details :
| AUO LCD SCREEN B156HAN06.1 HW2B | |
| Panel Brand | AUO |
| Panel Model | B156HAN06.1 HW2B |
| Panel Size | 15.6" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080 FHD 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.16(H)×193.59(V) mm |
| Outline Size | 359.5(H)×223.8(V) ×3.2(D) mm |
| Surface | Antiglare |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) [Transmission] |
| Viewing Angle | 85/85/85/85 (Typ.) (CR≥10) |
| View Direction | Symmetry |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) ms |
| Display Colors | 262K , 45% NTSC |
| Lamp Type | WLED , 15K hours, with LED driver |
| Frequency | 60Hz |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop |
| Touch Screen | Without |
| Signal Interface | eDP (2 Lanes) , 30 pins , terminal |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C |
| AUO Vertical Stripe 15.6 Inch LCD Pane B156HAN06.1 HW2B 1920*1080 30 pins | |
