6.0 Inch 480×272 LCD Screen Display Panel A060FW03 V0 RGB Stripe AUO LCD Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | A060FW03 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | A060FW03 V0 | Diagonal Size: | 6.0 Inch |
|---|---|---|---|
| Pixel Format: | 480×272(RGB) [WQVGA] 92PPI | Active Area: | 132.48(H)×75.072(V) Mm |
| Outline Dim.: | 143.9(H)×88.3(V)mm | Response Time: | 10/25 (Typ.)(Tr/Td) |
| Weight: | 87.0±0.9g | Application: | Digital Photo Frame / Portable DVD Player / Video Door Phone |
| High Light: | WQVGA LCD Screen Display Panel,auo lcd display A060FW03 V0,480×272 AUO LCD Display |
||
Product Description
6.0 inch 480×272 A060FW03 V0 LCD rgb stripe auo lcd display
A060FW03 V0 Product details :
| AUO LCD SCREEN A060FW03 V0 | |
| Panel Brand | AUO |
| Panel Model | A060FW03 V0 |
| Panel Size | 6.0" |
| Panel Type | LCM, a-Si TFT-LCD |
| Resolution | 480×272(RGB) [WQVGA] 92PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 132.48 × 75.072 mm (H×V) |
| Outline Size | 143.9 × 88.3 mm (H×V×D) |
| Surface | Matte, Hard coating (3H) |
| Brightness | 180 (Typ.) |
| Contrast Ratio | 300 : 1 (Typ.) [Transmission] |
| Viewing Angle | 70/70/50/50 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/25 (Typ.)(Tr/Td) ms |
| Display Colors | 16.7M , 46% NTSC |
| Lamp Type | WLED , no driver |
| Frequency | 60Hz |
| Panel Weight | 87.0±0.9g |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI , FPC , 50 pins |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -25 ~ 70 °C Operating temperature: 0 ~ 60 °C |
| 6.0 inch 480×272 A060FW03 V0 LCD rgb stripe auo lcd display | |
