21.5 Inch M215HJK-L3B LCD Screen Panel 1920*1080 LCD Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Innolux |
| Model Number: | M215HJK-L3B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | M215HJK-L3B | Panel Size: | 21.5" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 102PPI | Active Area: | 476.064(W)×267.786(H) Mm |
| Treatment: | Hard Coating (6H) | Outline Size: | 499.48(W)×291.24(H)×16.11(D) Mm |
| Work Mode: | MVA, Normally Black, Transmissive | Application: | Desktop Monitor |
| Color Depth: | 16.7M 72%NTSC | Backlight: | WLED, 40K Hours, No Driver |
| Highlight: | A040FL02 V2 LCD Screen Panel,Parallel RGB LCD Screen Panel,4.0 inch AUO LCD Display |
||
Product Description
21.5 Inch M215HJK-L3B LCD Screen Panel 1920*1080 LCD Display
M215HJK-L3B Product details :
| Brand | Innolux |
| Model P/N | M215HJK-L3B |
| Diagonal Size | 21.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 476.064(W)×267.786(H) mm |
| Bezel Opening | - |
| Outline Size | 499.48(W)×291.24(H)×16.11(D) mm |
| Treatment | Hard coating (6H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 20/5 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | MVA, Normally Black, Transmissive |
| Color Depth | 16.7M 72%NTSC |
| Backlight | WLED, 40K hours, No Driver |
| Mass | 2.55±0.12Kgs |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP, I²C/USB |
| Signal Type | LVDS (2 ch, 8-bit), 30 pinsConnector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
M215HJK-L3B Payment and Tax:
1.Alipay is perferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc.Those fees are not covered by either price or shipping charges of product,and are responsibility of recipient.
M215HJK-L3B Shipping and Package :
M215HJK-L3B Shipment:
Usually we will prepare and ship your goods within 5 business days.
The shipping charge doesn't include the import tax,buyer is responsible for custom duties.
Pls check if your item is in good condition upon receipt of it.
M215HJK-L3B Guarantee:
1.12 months Manufacturer's limited warranty for defective items (excluding items damaged and/or misused after receipt). Accessories come with a 3-month warranty.
2. Defective items MUST BE reported and returned within the warranty period(and in the original packaging, if possible). You must tell us what the defect is and give us your order number.WE Do NOT REPAIR OR REPLACE ITEMS WITH AN EXPIRED WARRANTY.
You agree to all of the above-listed policies upon ordering !
M215HJK-L3B Import Taxes or Duties:
1.-Import duties, taxes and other charges happened in your side are not included in the price of the item. These fees are afforded by buyer.
2.- Please check with you country's Customs office to determine what these additional costs will be before purchase.
3.-Please confirmed detailed information about delivery invoice. For example, how much price we should write on the waybill invoice, or how to describe the item, etc..
M215HJK-L3B FAQ:
Q: Can you give me a discount if I need a large quantity of M215HJK-L3B ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of M215HJK-L3B to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of M215HJK-L3B ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90 days warranty .
