AUO LQ156M1JW04 15.6 Inch LCD Panel 1920*1080 141PPI For Laptop / Gaming
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | LQ156M1JW04 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LQ156M1JW04 | Panel Size: | 15.6 Inch |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 141PPI | Display Area: | 344.16(W)×193.59(H) Mm |
| Outline Dim.: | 350.66(W)×215.54(H)×2.6(D) Mm | Viewing Angle: | 89/89/89/89 (Typ.) (CR≥10) |
| Number Of Colors: | 16.7M | Designed For: | Laptop / Gaming |
| High Light: | AUO 15.6 inch LCD panel,Antiglare 15.6 inch LCD panel,LQ156M1JW04 LCD Laptop Screen |
||
Product Description
AUO Vertical Stripe 15.6 Inch LCD Pane LQ156M1JW04 1920*1080 141PPI
LQ156M1JW04 Product details :
| Sharp LCD Screen LQ156M1JW04 | |
| Panel Brand | Sharp |
| Panel Model | LQ156M1JW04 |
| Screen Size | 15.6inches |
| Panel Type | Oxide TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 344.16(W)×193.59(H) mm |
| Outline(mm) | 350.66(W)×215.54(H)×2.6(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.) (CR≥10) |
| Reaction time | 8 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Optical mode | New Mode2, Normally Black, Transmissive |
| Number of colors | 16.7M |
| Backlight type | WLED , 15K hours, with LED driver |
| Refresh Rate | 240Hz |
| Touch Panel | Without |
| Appearance style | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop / Gaming |
| Signal | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins , terminal |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Operating: 0 ~ 50 °C ; Storage: -25 ~ 60 °C |
| AUO Vertical Stripe 15.6 Inch LCD Pane LQ156M1JW04 1920*1080 141PPI | |
LQ156M1JW04 About shipping method:
Due to the continuous impact of the COVID-19 epidemic, the logistics time limit is unstable. Some channels may be suspended at any time or some channels warehouses have a large backlog of goods. We would like to choose which logistics is more stable, fast and safe at certain times for buyer.
Such as buyer choose DHL, we may ship by the same level express like TNT, Fedex or UPS.If you need specified logistics, please tell us in advance.
LQ156M1JW04 Warning:
*Installation guide not included, We are not responsible for any damage caused by installation of this accessory, please be sure you know how to install it before bid,Thank you for your kind understanding!
*We just can guarantee the one you received that will be compatible with your tablet,
*Please DO NOT buy if you do not accept an A+ grade compatible touch screen digitizer with different flex cable numbers as our title/description/photo states is out of supply in the market, thank you!
1. Each screen is tested before shipping & 100% working;Repair/Replacing old, broken, cracked,damaged faulty touch screen.
2. After receiving the goods, do not tear the film, do not stick the glue on the back, test the machine first, remove the old screen, insert the new screen, and check whether the sensitivity is normal. Please be sure to try the machine first. Make sure the quality is ok. Install again.it is easy to burn the motherboard and touch screen, we are not responsible.
3.before connection test the power must be disconnected ,Otherwise it will burn the motherboard and touch screen easily.If it doesn't work, we won't be responsible.
LQ156M1JW04 About Shipping:
We will test them strictly before shipping.
we will ship it in 3 working days after your paying.Buyer is responsible for customs duty fee.
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
LQ156M1JW04 Guarantee And Return:
1. We offer guarantee for all our products.
2. Buyers will bear the shipping cost of returning defective or non-defective items.
3. Returned items must be in good condition like the one we send, not damaged.
4. Returned items are subject to approval by us, must be in the original box as shipped.
5. Damaged items received must be reported within 2 days.
6. All non-seller error returns,shipping and handling charges are non-refundable.
LQ156M1JW04 Import Taxes or Duties:
1.-Import duties, taxes and other charges happened in your side are not included in the price of the item. These fees are afforded by buyer.
2.- Please check with you country's Customs office to determine what these additional costs will be before purchase.
3.-Please confirmed detailed information about delivery invoice. For example, how much price we should write on the waybill invoice, or how to describe the item, etc..
LQ156M1JW04 FAQ:
Q: If I order LQ156M1JW04 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for LQ156M1JW04 ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods of LQ156M1JW04 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How can I trace my order of LQ156M1JW04 ?
A: we will give you tracking number then you can trace your order from website.
LQ156M1JW04 Shipping and Package :
