AUO B156XTN02.1 15.6 Inch LCD Panel 40 Pins LCD Laptop Screen
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | B156XTN02.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | B156XTN02.1 | Panel Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768 WXGA 100PPI | Display Area: | 344.232 × 193.536 Mm (H×V) |
| Outline Size: | 359.3 × 209.5 × 5.5 Mm (H×V×D) | Display Brightness: | 220 Cd/m² (Typ.) |
| Viewing Angle: | 45/45/15/35 (Typ.) (CR≥10) | Application: | Laptop |
| High Light: | Antiglare 15.6 inch LCD panel,AUO 40 Pins 15.6 inch LCD panel,B156XTN02.1 LCD Laptop Screen |
||
Product Description
AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN02.1 40 pins Laptop SCREEN
B156XTN02.1 Product details :
| AUO LCD SCREEN B156XTN02.1 | |
| Panel Brand | AUO |
| Panel Model | B156XTN02.1 |
| Panel Size | 15.6" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768 WXGA 100PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.232 × 193.536 mm (H×V) |
| Bezel Opening | 350.4 × 196.94 mm (H×V) |
| Outline Size | 359.3 × 209.5 × 5.5 mm (H×V×D) |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 220 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Viewing Angle | 45/45/15/35 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 8 (Typ.)(Tr+Td) ms |
| Display Colors | 262K , 60% NTSC |
| Lamp Type | WLED , 12K hours, with LED driver |
| Form Style | Wedge (PCBA Bent, T≥5.2mm) |
| Designed For | Laptop |
| Frequency | 60Hz |
| Touch Screen | Without |
| Signal Interface | LVDS (1 ch, 6-bit) , terminal, 40 pins |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN02.1 40 pins Laptop SCREEN | |
B156XTN02.1 Buyer Notice:
1. We are not responsible for any customs or import duties.
2.We will send the compatible one instead if the original one out of stock.which may not be exactly the same as the model of your original screen or inconsistent with the advertising picture in the product, but we can ensure that it is suitable for 100% model
B156XTN02.1 Our advantages:
1. The LCD screens you purchase are 100% original.
2. Our goods are in stock and shipped within 24 hours.
3. The customer installs independently and provides the installation tutorial instructions.
4. Our packaging is professionally customized and very safe! Each package will have a fragile label.
5. Product grades are available A+ (perfect) and A- (defective/imperfect) to meet various customer needs.
6. We provide professional after-sales service, 24 hours a day for customer service, and provide a 90-day warranty (calculated from the time the goods arrive at the destination).
B156XTN02.1 Attention:
To avoid wrong order placed or wrong item you bought, here is something you need to read before ordering,
1. Please check your laptop model in compatible list or tell if wide screen or standard screen.
2. Please check the LCD screen size and resolution.
3. Please check the Data connector (14pin, 20pin, 30pin(S M L) ,40pin(S,M,L), 50pin 60pin ) and position
4. Please check the physical resolution pixels of LCD screen.
B156XTN02.1 Important:
Specific laptop models can come in many sizes and resolutions. Laptop LCD resolution should not beupgraded or downgraded. You must confirm that this screen matches your laptop in size and in resolution before you purchase! No Returns Due To Improper Installation or Incompatibility
B156XTN02.1 Pay:
1: We accept Alipay, PayPal,
2: All major credit cards are accepted through secure payment processes-sor ESCROW
3: Make sure you read the entire description and agree to the Transaction before buying.
B156XTN02.1 Shipment Details:
1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.
2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days
3: If you do not receive the goods within 45 days, please contact us. And give us 3 business days to check the packages that are not delivered and the reasons. If this is our problem, we will refund your money.
B156XTN02.1 FAQ:
Q: When would you ship,IF I order B156XTN02.1?
A: The order are shipped within 1-2 working days after received the payment.
Q: How to order AUO B156XTN02.1 ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: Can you test 15.6 inch lcd panel B156XTN02.1 before shipping?
A: Don't Worry , The B156XTN02.1 will be tested ok before shipping.
Q: What happen if AUO B156XTN02.1 received can't work ?
A: Our AUO B156XTN02.1 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return.
B156XTN02.1 Shipping and Package :
