AUO Vertical Stripe 15.6 Inch LCD Pane B156HAN02.2 HWAA 40 pins LCD SCREEN
Product Details:
| Place of Origin: | Sharp |
| Brand Name: | AUO |
| Model Number: | B156HAN02.2 HWAA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | B156HAN02.2 HWAA | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080, FHD, 141PPI | Active Area: | 344.16(W)×193.59(H) Mm |
| Outline Dim.: | 350.56(H)×223.6(V) ×3.2(D) Mm | Display Brightness: | 250 Cd/m² (Typ.) |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) | Designed For: | Laptop |
Product Description
AUO Vertical Stripe 15.6 Inch LCD Pane B156HAN02.2 HWAA 40 pins LCD SCREEN
B156HAN02.2 HWAA Product details :
| Brand | AUO |
| Model Name | B156HAN02.2 HWAA (AUO22ED) |
| screen size | 15.6 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 1920(RGB)×1080 [FHD] 141PPI |
| Pixel arrangement | RGB vertical bar |
| Display size | 344.16(H)×193.59(V) mm |
| Outline Dim. | 350.56(H)×223.6(V) ×3.2(D) mm |
| Treatment | Antiglare |
| Display brightness | 250 cd/m² (Typ.) |
| Contrast | 700:1 (Typ.) (transmission) |
| Optical mode | AHVA, normally black display, transmissive |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response Time | 25 (Typ.)(Tr+Td) ms |
| Number of | 262K , 46% NTSC |
| Backlight type | WLED, 15K hours, with LED driver |
| Designed For | Laptop |
| Refresh rate | 60Hz |
| Touch Panel | Without |
| Interface Type | 40 pins eDP (2 Lanes), eDP1.2, connector |
| Supply voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
| AUO Vertical Stripe 15.6 Inch LCD Pane B156HAN02.2 HWAA 40 pins LCD SCREEN | |
B156HAN02.2 HWAA Note:
1: This product is a display screen, which needs to be installed by professionals. Please purchase with caution, thank you!
2: Purchasing this product, according to the buyer's choice of logistics, we will send it out within 48 hours, if there is a delay, please wait for the tracking information to prevail!
3: After receiving the product, if there is a problem, please contact customer service to solve it!
4: Our company is located in Shenzhen, China, and has the most advantageous resources. Wholesale more models display screen, If you have other needs, please contact customer service to obtain information and quotations!
B156HAN02.2 HWAA Shipment Details:
1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.
2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days
B156HAN02.2 HWAA About transportation
1: The recipient must be the company's full name or full name.
2: If the product ordered is very expensive, you need to get the packaging quickly. It is recommended to use DHL or EMS for transportation.
3: If you choose DHL shipping. Some DHL remote addresses require an additional remote address service fee, approximately $ 35. In some countries, aircraft cannot carry spare batteries. Some motherboards do not have a BIOS battery. You can use the original BIOS battery. I hope you can understand.
4: If a customs clearance fee is incurred, the buyer bears it.
5: After receiving the package, please check the package in time. If the packaging is damaged, save the video evidence. We can ask the logistics company to make up.
B156HAN02.2 HWAA Warranty:
1.- 90days' warranty..
2.-If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition)
3.-We supply free repairing service within one year of purchase. For the first 1 month, we will pay one way shipping cost( from us to your location); After 1 month of purchase, the buyer need to pay two ways of shipping cost.
4.- One we get the returned items, we will send the replaced ones back as soon as possible.
5.-Our warranty does not extend to any products that are physically damaged or under un-normal operating conditions as a result of misuse or
improper installation on the parts
B156HAN02.2 HWAA FAQ:
Q: How long will I receive my goods B156HAN02.2 HWAA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:If I place order now,when will you ship the goods of B156HAN02.2 HWAA ?
A: The order will be shipped within 2-3 working days after received your payment.
Q:Do you accept sample orders of B156HAN02.2 HWAA ?
A:Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
B156HAN02.2 HWAA Shipping and Package :
