Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX41 3840*2160 400 cd/m lcd screen
Product Details:
| Place of Origin: | Sharp |
| Brand Name: | Sharp |
| Model Number: | LQ156D1JX41 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LQ156D1JX41 | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 3840(RGB)×2160 (UHD) 283PPI | Active Area: | 344.218(H)×193.622(V) Mm |
| Outline Dim.: | 348.12(H)×214.12(V)×3.7(D) Mm | Luminance: | 400 Cd/m² (Typ.) |
| Viewing Angle: | 89/89/89/89 (Typ.) (CR≥10) | Designed For: | Laptop |
Product Description
Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX41 3840*2160 400 cd/m lcd screen
LQ156D1JX41 Product details :
| Sharp LCD Screen LQ156D1JX41 (SHP148D) | |
| Panel Brand | Sharp |
| Panel Model | LQ156D1JX41 (SHP148D) |
| screen size | 15.6 inches |
| Panel Type | LCM, Oxide TFT-LCD |
| Resolution | 3840(RGB)×2160 (UHD) 283PPI |
| Pixel configuration | RGB vertical bars |
| Display size | 344.218(H)×193.622(V) mm |
| Outline Dim. | 348.12(H)×214.12(V)×3.7(D) mm |
| Treatment | Glare (Haze 0%), Hard coating |
| Display brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 1500 : 1 (Typ.) [Transmission] |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.) (CR≥10) |
| Reaction time | 30 (Typ.)(Tr+Td) ms |
| Optical mode | IPS, Normally Black, Transmissive |
| Number of colors | 16.7M , 100% sRGB |
| Backlight type | WLED , 15K hours, with LED driver |
| Frame Rate | 60Hz |
| Touchscreen | Without |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Signal | eDP (4 Lanes) , eDP1.4a , 4.32G/lane , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -25 ~ 60 °C |
| Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX41 3840*2160 400 cd/m lcd screen | |
LQ156D1JX41 Buyer Notice:
1. We are not responsible for any customs or import duties.
2.We will send the compatible one instead if the original one out of stock.which may not be exactly the same as the model of your original screen or inconsistent with the advertising picture in the product, but we can ensure that it is suitable for 100% model
3.For all the problems, please do not leave negative feedback or open dispute before contacting us, Please send us message via AliExpress and we will solve the problem for you immediatel
4. Product grades are available A+ (perfect) and A- (defective/imperfect) to meet various customer needs.
5. Provide a 90-day warranty time, man-made damage and natural disasters are not covered by the warranty! (calculated from the time the goods arrive at the destination).
LQ156D1JX41 Shipment Details:
1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.
2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days
LQ156D1JX41 Shipment:
1.- We can ship the products all the world.
2.- DHL, FedEx, TNT, UPS, EMS, China Post, Hongkong Post are all available.
3.- The item will be sent out with 3days after receiving the payment.
4.- Please make sure your delivery address and contact telephone number are correct when you bid the item.
5.- You can track the situation of your product on website after they are shipped out
LQ156D1JX41 Warranty:
1.- 90days' warranty..
2.-If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition)
3.-We supply free repairing service within one year of purchase. For the first 1 month, we will pay one way shipping cost( from us to your location); After 1 month of purchase, the buyer need to pay two ways of shipping cost.
4.- One we get the returned items, we will send the replaced ones back as soon as possible.
5.-Our warranty does not extend to any products that are physically damaged or under un-normal operating conditions as a result of misuse or
improper installation on the parts
LQ156D1JX41 FAQ:
Q: If I order LQ156D1JX41 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for LQ156D1JX41 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of LQ156D1JX41 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of LQ156D1JX41 at a very low value ?
A: Yes , we can . pls inform us before shipping .
LQ156D1JX41 Shipping and Package :
