23.0 inch lcd panel module LTM230HT12 Suitable for Desktop Monitor
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Samsung |
| Model Number: | LTM230HT12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LTM230HT12 | Panel Size: | 23.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 95PPI | Active Area: | 509.76(W)×286.74(H) Mm |
| Bezel Opening: | 513.8(W)×290.8(H) Mm | Outline Size: | 534×311.7×10.7 (H×V×D) |
| Work Mode: | TN, Normally White, Transmissive | Application: | Desktop Monitor |
| Refresh Rate: | 60Hz | Signal Type: | LVDS (2 Ch, 8-bit), Connector30 Pins |
Product Description
23.0 inch lcd panel module LTM230HT12 Suitable for Desktop Monitor
LTM230HT12 Product details :
| Brand | Samsung |
| Model P/N | LTM230HT12 |
| Diagonal Size | 23.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 95PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 509.76(W)×286.74(H) mm |
| Bezel Opening | 513.8(W)×290.8(H) mm |
| Outline (mm) | 534×311.7×10.7 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 25 (Max.)(Tr+Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 72%NTSC |
| Backlight | 11S3PWLED, 40K hours, No Driver |
| Mass | 2.10Kgs (Max.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit), Connector30 pins |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
LTM230HT12 Buyer must read!!!
Pls note:
1:Description before buying, please carefully read the title, please make sure the LCD Screen models and machine models, if not sure, right to buy the product does not match the work, this is the responsibility as a buyer, we are not responsible for, we can accept the return of goods, but we will not bear the transportation cost, if you have not understand problem, you can always send email to us, we will reply to your mail, thank you!
2.These products are used, the LCD Screen components no any broken,we will test it before we sent ,
3. All product have been tested before shipping. If the product is faulty during shipping, please inform us immediately after your received it.
4: Don't open a dispute because the product is old. We have a detailed description. If you can't accept it, please don't make the order, and avoid causing unnecessary disputes. Thank you!
5:Part of the product is new and original, in the case of inventories have new stock, we will send all the new products, if in the case of new stock sold out, we will send the old products, but all products are strictly tested before sending, so don't worry!hope you can understand!
6:All products have a three-month guarantee period if have any quality problems, you can contact to us ,we can change goods and maintenance, If you are not satisfied, We will try our best to satisfy you without any loss. donot worry
LTM230HT12 Shipping and Package :
LTM230HT12 ATTENTION:
if you do agreed as following, PLS CANCEL THE ORDER!!!!!!!!!!!!!!!!!
If you choose DHL, do pls be sure your ADD is not remote area, otherwise, you have to pay for the addtional remote fee
All the items must still with our lable marking guarantee day .Without of it , the item is not belong to me.
1) After receiving, if you find the package or the item is damaged, do pls reject, at lease, pls take a video for opening . otherwise, the buyer should take the responsibility of the package.
2) China post cost 1-1.5 months usually. If the package is delay, pls contact with me, I do will extend the delivery day.
3)The payment buyer transfered exincluding the tax, if buyer reject to pay if it happen and reject of the package, then no refund.
thank you
LTM230HT12 Should returns be required:
Step 1 Contact us via message center
Step 2 Provide as much detail as possible about the problem you are having
Step 3 Authorization to return the item will be issued
Step 4 Return the item for the agreed exchange or refund
*All return shipping costs are the responsibility of the buyer
LTM230HT12 FAQ:
Q: Can you test the lcd panel LTM230HT12 before shipping ?
A: Yes , of course , don't worry , our item was tested ok before shipping .
Q: Do you accept the sample order LTM230HT12?
A: Yes , sample order is welcome.
Q: Can you declared low value of my order LTM230HT12?
A: Yes , we can , you can tell us before shipping .
Q: How long the warranty of lcd LTM230HT12?
A: 90 days .
