27.0 inch lcd panel module LTM270HL01 1920*1080 LCD Screen Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Samsung |
| Model Number: | LTM270HL01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTM270HL01 | Screen Size: | 27.0" |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD 81PPI | Active Area(mm): | 597.888(W)×336.312(H) Mm |
| Luminance: | 300 Cd/m² (Typ.) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Backlight: | 13S3PWLED, 40K Hours, Without Driver | Used For: | Desktop Monitor |
| Environment: | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C | Signal Interface: | LVDS (2 Ch, 8-bit), 30 Pins Connector |
Product Description
27.0 inch lcd panel module LTM270HL01 1920*1080 LCD Screen Display
LTM270HL01 Product details :
| Brand | Samsung |
| Model P/N | LTM270HL01 |
| Diagonal Size | 27.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 597.888(W)×336.312(H) mm |
| Bezel Opening | 602.0(W)×340.4(H) mm |
| Outline Size | 630(W)×368.2(H)×14.6(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | PLS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 15 (Typ.)(G to G) |
| Display Colors | 16.7M 72%NTSC |
| Lamp Type | 13S3PWLED, 40K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 3.80Kgs (Max.) |
| Application | Desktop Monitor |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
LTM270HL01 Attention Note:
1.match the shown in the photo to the originals in your LCD Display. If you are not sure if it is compatible, you can turn on the inside of the LCD Screen, take a photo and provide it to me. Thank you very much.
2.Please fill out the complete consignee name, address, telephone number, zip code,tax number.
3. If you cannot track the package information, please contact me in time, thank you
LTM270HL01 Purchase considerations:
The product will be tested before shipment, it will be in good condition, please feel free to contact us if there is any problem with the product. After we receive your order payment, we will send it within 1~3 business days.
We will send you via ALI Standard Logistics, ALI Priority Logistics, DHL, EMS, FedEx (the shipping method depends on your options).
For all customer orders, we do not charge handing fee, even 1pcs part.When parts arrived at your local custom, if the parts were charged customs duty, we do not responsible for any custom duty or import tax.Make sure you read the shipping details determine the expected delivery time. If the project still did not arrive at this time, please give us a message, prolong of acknowledgement of receipt of this order.
Please check after receiving the goods. If the product is not satisfactory, you need to return the refund.Please contact us before returning the goods and the return must be in a new state (the buyer should return all original and undamaged items under resale conditions).
LTM270HL01 Shipping and Package :
LTM270HL01 About packaging:
Large volume purchase requires hard paper packaging and is also very safe
LTM270HL01 Shipment Details:
1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.
2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days
3: If you do not receive the goods within 45 days, please contact us. And give us 3 business days to check the packages that are not delivered and the reasons. If this is our problem, we will refund your money.
LTM270HL01 Warranty is void if:
1.LCD Display or touch is broken by man-made reasons.
2. Glue or stick the screen to the device before test it work.
3. Water-in to the screen.
4. Self-repair or disassemble without permission by our side.
5. Warranty label is removed. To protect the screen, please power off the phone before replacement.
To lower the risk of damage, we advise you to repair it at your local repair store.
LTM270HL01 FAQ:
Q: Do you accept sample orders of LTM270HL01 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of LTM270HL01 vai credit card ?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of LTM270HL01 ?
A: The order will be shipped within 2-3 working days after received your payment.
