Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX01 3840*2160LCD modules
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Sharp |
| Model Number: | LQ156D1JX01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ156D1JX01 | Screen Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Number: | 3840(RGB)×2160(UHD) 282PPI | Active Area(mm): | 345.6(H)×194.4(V) Mm |
| Outline(mm): | 367.98 × 224.61 × 3.4 (H×V×D) | Viewing Angle: | 88/88/88/88 (Typ.) (CR≥10) |
| Number Of Colors: | 16.7M 100% SRGB | Used For: | Laptop |
Product Description
Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX01 3840*2160LCD modules
LQ156D1JX01 Product details :
| Sharp LCD Screen LQ156D1JX01 (SHP1414) | |
| Panel Brand | Sharp |
| Panel Model | LQ156D1JX01 (SHP1414) |
| screen size | 15.6inches |
| Panel Type | LCM, Oxide TFT-LCD |
| Resolution | 3840(RGB)×2160(UHD) 282PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 345.6(H)×194.4(V) mm |
| Outline Dim. | 367.98 × 224.61 × 3.4 (H×V×D) |
| Luminance | Mirror (Haze 0%), Hard coating (3H) |
| Display brightness | 330 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (Transmission) |
| Viewing Angle | 88/88/88/88 (Typ.) (CR≥10) |
| Reaction time | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Optical mode | IPS, Normally Black, Transmissive |
| Number of colors | 16.7M 100% sRGB |
| Backlight type | WLED , 10K hours, with LED driver |
| Frame Rate | 60Hz |
| Touchscreen | Without |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Signal | 40 pins eDP (4 Lanes) , terminal |
| drive voltage | 3.3V (Typ.) |
| working | Operating: 0 ~ 50 °C ; Storage: -20 ~ 60 °C |
| Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156D1JX01 3840*2160LCD modules | |
LQ156D1JX01 Attention:
We will send compatible model based on inventory.If you don't accept it ,please do not order it.Thanks
LQ156D1JX01 NOTE:
Before you ordered , in case of any mistake & trouble in our business , please mail us as below information for double confirming to win this deal together.
•1-->LCD model name in your hand now ,such as : LP140WH1-TLA1
•2-->Your laptop name ,such as : DV3000 ......
•3-->Send above information to our mail and we will response you within 24 hours for quick and right deal ,thanks !
LQ156D1JX01 Attention:
To avoid wrong order placed or wrong item you bought, here is something you need to read before ordering,
1. Please check your laptop model in compatible list or tell if wide screen or standard screen.
2. Please check the LCD screen size and resolution.
3. Please check the Data connector (14pin, 20pin, 30pin(S M L) ,40pin(S,M,L), 50pin 60pin ) and position
4. Please check the physical resolution pixels of LCD screen.
LQ156D1JX01 Important:
Specific laptop models can come in many sizes and resolutions. Laptop LCD resolution should not beupgraded or downgraded. You must confirm that this screen matches your laptop in size and in resolution before you purchase! No Returns Due To Improper Installation or Incompatibility
LQ156D1JX01 Information:
We accept Escrow service, T/T(Telegraphic Transfer), Western Union, Paypal, MoneyGram, China Bank Transfer.
LQ156D1JX01 Shipment:
Usually we will prepare and ship your goods within 5 business days.
The shipping charge doesn't include the import tax,buyer is responsible for custom duties.
Pls check if your item is in good condition upon receipt of it.
LQ156D1JX01 Warranty is void if:
1.LCD Display or touch is broken by man-made reasons.
2. Glue or stick the screen to the device before test it work.
3. Water-in to the screen.
4. Self-repair or disassemble without permission by our side.
5. Warranty label is removed. To protect the screen, please power off the phone before replacement.
To lower the risk of damage, we advise you to repair it at your local repair store.
LQ156D1JX01 FAQ:
Q: Can I pay my order of LQ156D1JX01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of LQ156D1JX01 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of LQ156D1JX01 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90 days warranty .
LQ156D1JX01 Shipping and Package :
