AA121XH03 Original 12.1 inch CCFL TFT industrial lcd panel 105ppi LCD Display Screen RoHS Compliant
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Mitsubishi |
| Model Number: | AA121XH03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | AA121XH03 | Panel Size: | 12.1" |
|---|---|---|---|
| Resolution: | 1024(RGB)×768, XGA, 105PPI | Display Area: | 245.76(W)×184.32(H) Mm |
| Bezel Opening: | 249.0(W)×187.5(H) Mm | Outline Size: | 280(W)×210(H)×12.5(D) Mm |
| Panel Weight: | 720g (Typ.) | Application: | Industrial |
Product Description
AA121XH03 Original 12.1 inch CCFL TFT industrial lcd panel 105ppi LCD Display Screen RoHS Compliant
AA121XH03 Product details :
| Mitsubishi LCD SCREEN AA121XH03 | |
| Manufacturer | Mitsubishi |
| Model Name | AA121XH03 |
| Screen Size | 12.1 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 105PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 245.76 × 184.32 (H×V) |
| Outline(mm) | 280 × 210 × 12.5 (H×V×D) |
| Bezel Area(mm) | 249.0 × 187.5 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 320 cd/m² (Typ.) |
| Contrast Ratio | 550 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/45/75 (Typ.)(CR≥10) |
| Response | 6/19 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 40% NTSC |
| Backlight | 2 pcs CCFL , 50K hours , No Driver |
| Mass | 720g (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AA121XH03 Original 12.1 inch CCFL TFT industrial lcd panel 105ppi LCD Display Screen RoHS Compliant | |
AA121XH03 Our advantages:
1: We are all own stock, with adequate supply
2: The quality of the product reached a series of certification
3: We support a variety of transportation, Hong Kong and the Chinese postal packets, EMS.DHL federal .UPS and TNT, can fully meet the different needs of the buyer.
AA121XH03 Shipping and Package :
AA121XH03 Shipment:
1.- We can ship the products all the world.
2.- DHL, FedEx, TNT, UPS, EMS, China Post, Hongkong Post are all available.
3.- The item will be sent out with 3days after receiving the payment.
4.- Please make sure your delivery address and contact telephone number are correct when you bid the item.
5.- You can track the situation of your product on website after they are shipped out
AA121XH03 Import Taxes or Duties:
1.-Import duties, taxes and other charges happened in your side are not included in the price of the item. These fees are afforded by buyer.
2.- Please check with you country's Customs office to determine what these additional costs will be before purchase.
3.-Please confirmed detailed information about delivery invoice. For example, how much price we should write on the waybill invoice, or how to describe the item, etc..
AA121XH03 Warranty is void if:
1.LCD Display or touch is broken by man-made reasons.
2. Glue or stick the screen to the device before test it work.
3. Water-in to the screen.
4. Self-repair or disassemble without permission by our side.
5. Warranty label is removed. To protect the screen, please power off the phone before replacement.
To lower the risk of damage, we advise you to repair it at your local repair store.
AA121XH03 FAQ:
Q: If I place order now,when will you ship the goods of AA121XH03?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How can I trace my order of AA121XH03 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of AA121XH03 ?
A: Of course!sample order is welcome !
Q: Can I pay my order of AA121XH03 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
