Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156M1JW03 1920*1080 141PPI
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Sharp |
| Model Number: | LQ156M1JW03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LQ156M1JW03 | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080, FHD, 141PPI | Active Area: | 344.16(W)×193.59(H) Mm |
| Outline Dim.: | 350.66(W)×215.54(H)×2.6(D) Mm | Outline Shape: | Slim (PCBA Flat, T≤3.2mm) |
| Number Of Colors: | 16.7M , 100% SRGB | Designed For: | Laptop / Gaming |
Product Description
Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156M1JW03 1920*1080 141PPI
LQ156M1JW03 Product details :
| Sharp LCD Screen LQ156M1JW03 (SHP14C5) | |
| Panel Brand | Sharp |
| Panel Model | LQ156M1JW03 (SHP14C5) |
| Screen size | 15.6 inches |
| Panel Type | Oxide TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Pixel configuration | RGB vertical bars |
| Display size | 344.16(W)×193.59(H) mm |
| Outline(mm) | 350.66(W)×215.54(H)×2.6(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Display brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.) (CR≥10) |
| View Direction | Symmetry |
| Reaction time | 8 (Typ.)(Tr+Td) ms |
| Optical mode | New Mode2, Normally Black, Transmissive |
| Number of colors | 16.7M , 100% sRGB |
| Backlight type | WLED , 15K hours, with LED driver |
| Refresh Rate | 240Hz |
| Touch Panel | Without |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop / Gaming |
| Signal | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins , terminal |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Operating: 0 ~ 50 °C ; Storage: -25 ~ 60 °C |
| Sharp Vertical Stripe 15.6 Inch LCD Pane LQ156M1JW03 1920*1080 141PPI | |
LQ156M1JW03 NOTE:
1.Before you place your order, if you are not sure which screen model you need, please be sure to contact customer service and we will get back to you promptly.
2.We may ship a compatible screen model according to the inventory. If you need to specify the model, please leave a message or contact customer service.
•3-->The LCD model name in your hand, such as: LM140LF1L02
•4-->Your notebook computer name, such as: brand,specific model
•5-->Send the above information to us, we will reply you with fast and correct transaction within 24 hours, thank you!
LQ156M1JW03 Product Description:
1: To Repair for Faulty Screen, Dead Pixels , Touch is not sensitive, Cracked Broken Touch Screen Problems.
2: Full Tested 100% Working By Real equipment before Shipping
3: Not supply the disassembly installation instructions and Tools
4: Please match your original screen with the image & description we have provided in this listing. If not sure. Contact with us to Confirm
5: We reserve the right to ship COMPATIBLE screens (part # or manufacturers may not be the same but 100% compatibility is guaranteed)
LQ156M1JW03 Packing:
The screen will be wrapped with Cardboard, and put in a super hard Box to make sure it is 100% safe. And we will put a protected film onto the screen to protect it from Scratches.
LQ156M1JW03 Shipping details:
1. We support shipment by AliExpress Standard Shipping ,ePacket, Singapore Post, e-EMS, DHL etc. If you want to select a fast and reliable shipping company, please feel free to contact us directly after paying.
2. Shipping time: We will ship your goods in 1-2 days after confirming the screen is suitable for your laptop. So please tell us the model of your laptop or screen quickly so that we can ship your goods as soon as possible.
3. General arrived time:
1)Expited Shipping:
DHL,UPS,TNT,Fedex,to worldwide 3-7 Days.
2)Standard Shipping Method:
European Countres : Russia,Spain,UK,France,Netherlands etc 10-20 days
North Ameriacan Countries: USA,Canada, etc 7-20 days.
Asia Countries:Singapore,Malaysia,Japan,India,etc 13-20 days
Other Remote Countries: 25-35 days
LQ156M1JW03 After-Sale:
If you have any problem after receiving your goods, don't give bad feedback first, please provide us with the proof of video or photo about the problems of your goods, we will offer replacement immediately or refund after confirming the problem.
If you have any questions in the process of purchase, please feel free to contact us. We will reply immediately.
LQ156M1JW03 Return:
All returns must be informed before returning.
The Buyer is ought to notify the seller of all returned items within 7 days after receiving the package. We reserve the right refusing any requirement that informs the seller longer than 7 days.
Exchange due to buyer wrong part ordered, buyer needs to pay 2-ways shipping fee.
Return items must have all original packaging and in good condition.
Return postage and insurance charge is non-refundable for refund or new shipment.
Shipping fees are non-refundable.
LQ156M1JW03 FAQ:
Q: How to make payment of LQ156M1JW03 ?
A: We accept T/T , Paypal , western union .
Q: If I place order now,when will you ship the goods of LQ156M1JW03 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long will I receive my goods LQ156M1JW03 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty ?
A: We offer 90 days warranty .
