12.1 inch industrial lcd panel 105ppi TFT screen AA121XL01 lcd manufacture
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Mitsubishi |
| Model Number: | AA121XL01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | AA121XL01 | Diagonal Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Format: | 1024(RGB)×768 [XGA] 105PPI | Active Area: | 245.76(H)×184.32(V) Mm |
| Outline Dim.: | 260.5(H)×203(V)×10.2(D) Mm | Bezel Area: | 249.0(H)×187.5(V) Mm |
| Weight: | 610g (Typ.) | Designed For: | Industrial / Outdoor High Brightness |
Product Description
12.1 inch industrial lcd panel 105ppi TFT screen AA121XL01 lcd manufacture
AA121XL01 Product details :
| Mitsubishi LCD SCREEN AA121XL01 | |
| Manufacturer | Mitsubishi |
| Model Name | AA121XL01 |
| Screen Size | 12.1 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 105PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 245.76 × 184.32 (H×V) |
| Outline(mm) | 260.5 × 203 × 10.2 (H×V×D) |
| Bezel Area(mm) | 249.0 × 187.5 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Response | 6/19 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 40% NTSC |
| Backlight | 4 strings WLED , 100K hours , No Driver |
| Mass | 610g (Typ.) |
| Used for | Industrial Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| 12.1 inch industrial lcd panel 105ppi TFT screen AA121XL01 lcd manufacture | |
AA121XL01 Welcome to our shop:
Why we were directly selected:
1. 12-month product warranty (excluding man-made damage)
All the goods for sale are in stock, and we can deliver the goods to you within 3 working days.
3. We have many different kinds of goods
What's more, you will get the lowest price with high quality
AA121XL01 Payment:
T/T (Wire Transfer)/Western Union/Paypal ,Escrow .
AA121XL01 Shipping and Package :
AA121XL01 Shipment:
1. Item will be shipped out within 1-3 days.
2. Make sure your address is correct (full name is recommended). We are not responsible for any wrong or undeliverable address.
3. We are not responsible for the possibly additional import duties, remote area charges, taxes or other Customs related fee.
4. Delivery time:
--via DHL, Fedex, UPS: 3-7 working days
--via EMS: 7-15 working days
--via Air Mail or Parcel: 10-30 working days (sometimes longer)
AA121XL01 Returns & Warranty:
All of our brand new items come with a 30-Days money-back guarantee.
We will replace the defective items,provided that they are in stock within the warranty period posted with the listing and the buyer return the original item and pay for the S&H cost for the replacement.
We will refund the purchase price if the replacement is not available or buyer prefers a refund and send the original item back at his/her own cost.
Shipping & handling cost are not refundable.
Man-made damage by abuse or wrong operation is not covered by this warranty.
No product liability insurance is assumed.
AA121XL01 FAQ:
Q: How can I trace my order of AA121XL01 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long will I receive my goods AA121XL01 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can you give me a discount if I need a large quantity of AA121XL01 ?
A: Of course!If you make a large order, we will give you a discount.
