Name: AUO 12.1 inch LCD Screen G121XN01 V001 with industrial lcd panel 105ppi
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: G121XN01 V001
Availability: InStock

Brand Name:	AUO
Model Number:	G121XN01 V001
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Model:

G121XN01 V001

Diagonal Size:

12.1 Inch

Pixel Format:

1024(RGB)×768 [XGA] 105PPI

Active Area:

245.76(H)×184.32(V) Mm

Outline Dim.:

279(H)×209(V)×9(D) Mm

Bezel Area:

250.8(H)×189.4(V) Mm

Weight:

510g (Max.)

Designed For:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

AUO 12.1 inch LCD Screen G121XN01 V001 with industrial lcd panel 105ppi

G121XN01 V001 Product details :

AUO LCD SCREEN G121XN01 V001
Panel Brand	AUO
Panel Model	G121XN01 V001
Panel Size	12.1"
Panel Type	a-Si TFT-LCD , LCM
Resolution	1024(2)×768(2), XGA, 105PPI
Pixel Format	RGB Vertical Stripe
Display Area	245.76(W)×184.32(H) mm
Bezel Opening	250.8(W)×189.4(H) mm
Outline Size	279(W)×209(H) ×9(D) mm
Surface	Antiglare, Hard coating (3H)
Brightness	500 cd/m² (Typ.)
Contrast Ratio	700:1 (Typ.) (TM)
Viewing Angle	80/80/70/70 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Response Time	25/10 (Typ.)(Tr/Td)
Display Colors	262K/16.2M 72% NTSC
Lamp Type	9S2P WLED , 50K hours , With LED Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	510g (Max.)
Signal Interface	LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C
AUO 12.1 inch LCD Screen G121XN01 V001 with industrial lcd panel 105ppi

G121XN01 V001 Products and services:

&Our company mainly sales of LCD panel and touch screen,

& We have thousands of models and products.So we are able to meet consumer demand.

& we offer high quality, fast delivery, competitive price for our customers

& Please send your RFQ(request for quoting) to get latest price.

& Warranty of each part.

& Terms of Payment:Paypal,TT,Escrow,Western Union

G121XN01 V001 Shipping and Package :

1.All the goods are packaged carefully with waterproof film

2.Protected by Hard Cartoon or Wooden Case

3.Lead time: generally 3-5 days after getting payment

4.We have international logistics company,more choices for shipment and more cheap,like FedEX,DHL,TNT,UPS,By Sea/Air

AUO 12.1 inch LCD Screen G121XN01 V001 with industrial lcd panel 105ppi 0

G121XN01 V001 Return and exchange rules:

Return of goods: on the premise of not affecting the second sale, return of goods for personal reasons such as quality problems, and the freight is borne by the buyer.

Replacement: the same product, non-human damage can be replaced; lf you need to replace different types of goods, you need to refund the ori-ginal products and pay under the auction.

G121XN01 V001 FAQ:

Q: Can you give me a discount if I need a large quantity of G121XN01 V001 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can You declare my order of G121XN01 V001 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long will I receive my goods G121XN01 V001 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: How to make payment of G121XN01 V001 ?

A: We accept T/T , Paypal , western union .
