Name: 10.4in 800(RGB)×600 auo tft lcd Display Panel G104SN03 V4 for Industrial
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: G104SN03 V4
Availability: InStock

Brand Name:	AUO
Model Number:	G104SN03 V4
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Model:

G104SN03 V4

Diagonal Size:

10.4 Inch

Pixel Format:

800(RGB)×600 [SVGA] 96PPI

Active Area:

211.2(H)×158.4(V) Mm

Outline Dim.:

236(H)×174.3(V)×6(D) Mm

Bezel Area:

214.8(H)×162.0(V) Mm

Weight:

TBD

Designed For:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

10.4in 800(RGB)×600 auo tft lcd Display Panel G104SN03 V4 for Industrial

G104SN03 V4 Product details :

AUO LCD SCREEN G104SN03 V4
Panel Brand	AUO
Panel Model	G104SN03 V4
Panel Size	10.4"
Panel Type	a-Si TFT-LCD , LCM
Resolution	800(RGB)×600, SVGA, 96PPI
Pixel Format	RGB Vertical Stripe
Display Area	211.2(W)×158.4(H) mm
Bezel Opening	214.8(W)×162.0(H) mm
Outline Size	236(W)×176.9(H) ×6(D) mm
Brightness	230 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)
Viewing Angle	80/80/60/80 (Typ.)(CR=10)
Display Mode	TN, Normally White, Transmissive
Response Time	10/20 (Typ.)(Tr/Td)
Display Colors	262K/16.2M 45% NTSC
Lamp Type	1 pcs CCFL , 30K hours , Without Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	TBD
Signal Interface	LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
10.4in 800(RGB)×600 auo tft lcd Display Panel G104SN03 V4 for Industrial

G104SN03 V4 Our Service:

Payment:T/T, Bank transfer ,western union , Others can be in consideration.

After-sales service:If you have any problem about product, please feel free to contact us. We will reply you within 12 hours.

Warranty: Usually, product warranty for 180days.

MOQ:1 piece or Sample order will be available.

Advantages:Best Price, High Quality, Fast Delivery, Good Service, Responsible Salesperson.

Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.

Quality:100% Grade A tested before shipping

G104SN03 V4 Shipping and Package :
10.4in 800(RGB)×600 auo tft lcd Display Panel G104SN03 V4 for Industrial 0

G104SN03 V4 Package:

Our packaging is all original carton packaging, details are shown above.

The original packaging design is very practical and secure, which greatly avoids the possible damage caused by transportation.

The general packaging quantity is 20/40/48/60pcs per carton, depends on size.

G104SN03 V4 About Shipping:

1: Shipping time
Cargo will be shipped within three days upon the receipt of payments.

2: Shipping port
Hong Kong/Shenzhen

3:Express
We can ship through DHL;FedEx;VPS;TNT;EMS;Air Cargo;Sen Cargo or through yourown forwarder.

G104SN03 V4 WARRANTY:

We suuport 1 year warranty.

If it is not man-made damage, we can repair it for free.

All the material were tested by IQC as soon as it's coming to our factory.

All the finished goods tested by QA before shipping out.

G104SN03 V4 FAQ:

Q: How can I trace my order of G104SN03 V4 ?

A: we will give you tracking number then you can trace your order from website.

Q: Can you give me a discount if I need a large quantity of G104SN03 V4 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How to make payment of G104SN03 V4 ?

A: We accept T/T , Paypal , western union .

Q: Can I pay my order of G104SN03 V4 via credit card ?

A: Yes!you can use your credit card through your Paypal account.
