AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | B156XTN08.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | B156XTN08.1 | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Type: | A-Si TFT-LCD , LCM | Active Area: | 1366(RGB)×768 WXGA 100PPI |
| Outline Dim.: | 350.66 × 216.15 × 3.2 Mm (H×V×D) | Bezel Area: | 344.232 × 193.536 Mm (H×V) |
| Color Depth: | 262K , 45% NTSC | Used For: | Laptop |
Product Description
AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI
B156XTN08.1 Product details :
| AUO LCD SCREEN B156XTN08.1 | |
| Panel Brand | AUO |
| Panel Model | B156XTN08.1 |
| Panel Size | 15.6" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768 WXGA 100PPI |
| Pixel Format | RGB vertical bars |
| Display Area | 344.232 × 193.536 mm (H×V) |
| Outline Size | 350.66 × 216.15 × 3.2 mm (H×V×D) |
| Treatment | Antiglare |
| Brightness | 220 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Viewing Angle | 45/45/15/35 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 8(Typ.)(Tr/Td) ms |
| Display Colors | 262K , 45% NTSC |
| Lamp Type | WLED , 15K hours, with LED driver |
| Designed For | Laptop |
| Frequency | 60Hz |
| Touch Screen | Without |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI | |
Hello, dear customers. Welcome to our shop.
We sell all brands of laptop screens, such as the screen for Lenovo HP Asus Acer Dell, and so on. If you need any other laptop screens, please feel free to contact us.
B156XTN08.1 Attention before buying:
To avoid mistakes, please send us your screen backside photo or laptop model label photo after placing an order. We will ship your goods as soon as possible after confirming the screen is suitable for your laptop.
B156XTN08.1 Our features :
1. Original quality guarantee.
2. Superior After-Sale service;
3. The most competitive prices here can provide;
4. Small order quantity accepted.
5. Offer 12 months of warranty;
6. Experienced staff can help you to solve your problem anytime.
B156XTN08.1 Payment Items:
Wire Transfer /MoneyGram /Western Union / PayPal /WeChat Pay / AliPay / Credit Card
B156XTN08.1 Packaging:
Normal packagingExport carton
custom packing
B156XTN08.1 Shipment Details:
1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.
2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days
B156XTN08.1 FAQ:
Q: Can I pay my order of B156XTN08.1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of B156XTN08.1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of B156XTN08.1 ?
A: We accept T/T , Paypal , western union .
