Name: 42.0 inch tft lcd display module P420HW02 V0 LCD Screen Panel for Digital Signage
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: P420HW02 V0
Availability: InStock

Brand Name:	AUO
Model Number:	P420HW02 V0
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Model:

P420HW02 V0

Diagonal Size:

42 Inch

Type:

A-Si TFT-LCD, LCM

Active Area:

930.24(H)×523.26(V) Mm

Outline Dim.:

957.45(H)×550.2(V)×54.2(D) Mm

Bezel Area:

939.0(H)×531.0(V) Mm

Spliced Seam:

27.2 Mm (active To Active Seam)

Designed For:

Digital Signage / Video Wall

Supply Ability:

100000 Unit/Units per Month

Product Description

42.0 inch tft lcd display module P420HW02 V0 LCD Screen Panel for Digital Signage

P420HW02 V0 Product details :

AUO LCD SCREEN P420HW02 V0
manufacturer	AUO
Model Name	P420HW02 V0
screen size	42 inch
Screen type	a-Si TFT-LCD , LCM
Resolution	1920(RGB)×1080 FHD 52PPI
Pixel configuration	RGB vertical bars
Display size	930.24(H)×523.26(V) mm
physical dimension	957.45(H)×550.2(V)×54.2(D) mm
Visual size	939.0(H)×531.0(V) mm
surface treatment	Matte (Haze 11%), Hard coating (3H)
Brightness	700cd/m² (Typ.)
Contrast	3500:1 (Typ.) (TM)
Best angle	Full view
Optical mode	AMVA3, Normally Black, Transmissive
Viewing angle	89/89/89/89 (Typ.)(CR≥10)
Responding time	8 (Typ.)(G to G) ms
Number of color	16.7M/1.07B , 72% NTSC
Backlight type	CCFL [16 pcs] , 60K hours, with inverter
Spliced Seam	27.2 mm (active to active seam)
Apply to	digital signage / multi-screen
Refresh rate	60Hz
Touch function	No touch
signal system	51 pins LVDS (2 ch, 8/10-bit) , terminal
Supply voltage	12.0V (Typ.)
Maximum rating	Operating temperature: 0 ~ 50 °C ; Storage temperature: -10 ~ 60 °C
42.0 inch tft lcd display module P420HW02 V0 LCD Screen Panel for Digital Signage

Why choose us P420HW02 V0 ?

P&O has more than 10 years experience in TFT lcd module.

We are a factory with best price and quality ,including 10+ engineers and a professional international sales team.

The quality is strictly controlled by 24 hours aging test,aslo for high-low temperature test.

P420HW02 V0 Our features :

1. Original quality guarantee.

2. Superior After-Sale service;

3. The most competitive prices here can provide;

4. Small order quantity accepted.

5. Offer 12 months of warranty;

6. Experienced staff can help you to solve your problem anytime.

P420HW02 V0 Payment Items:

Wire Transfer /MoneyGram /Western Union / PayPal /WeChat Pay / AliPay / Credit Card

P420HW02 V0 Shipping and Package :
42.0 inch tft lcd display module P420HW02 V0 LCD Screen Panel for Digital Signage 0

P420HW02 V0 Packaging:

Normal packagingExport carton

custom packing

P420HW02 V0 Delivery:

Items will be shipped within 3 working days after payment is received.

By DHL/UPS/FedEx/TNT: about 2-5 working days.

By EMS: about 7-10 working days.

By CPAM/HKPAM: about 10-30 working days.

P420HW02 V0 FAQ:

Q: Can You declare my order of P420HW02 V0 at a very low value ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty of P420HW02 V0 ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of P420HW02 V0 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How can I trace my order of P420HW02 V0 ?

A: we will give you tracking number then you can trace your order from website.
