AUO LCD Panel P420IVN01.0 42.0 inch tft lcd display module
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | P420IVN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | P420IVN01.0 | Panel Size: | 42" (4/9 Cut Of 47") |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Display Area: | 1039.68(W)×259.92(H) Mm |
| Bezel Opening: | 043.68(W)×263.92(H) Mm | Outline Size: | 1059.48(W)×283.52(H)×56.9(D) Mm |
| Panel Weight: | 5.5Kgs (Typ.) | Application: | Digital Signage / Stretched Bar LCD |
Product Description
AUO LCD Panel P420IVN01.0 42.0 inch tft lcd display module
P420IVN01.0 Product details :
| AUO LCD SCREEN P420IVN01.0 | |
| Panel Brand | AUO |
| Panel Model | P420IVN01.0 |
| Panel Size | 42" (4/9 cut of 47") |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×480, 46PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1039.68(W)×259.92(H) mm |
| Bezel Opening | 1043.68(W)×263.92(H) mm |
| Outline Size | 1059.48(W)×283.52(H) ×56.9(D) mm |
| Surface | Antiglare (Haze 44%), Hard coating (3H) |
| Brightness | 700 cd/m² (Typ.) |
| Contrast Ratio | 4000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AMVA3, Normally Black, Transmissive |
| Response Time | 8 (Typ.)(G to G) |
| Display Colors | 16.7M/1.07B 99% sRGB |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 5.5Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8/10-bit) , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AUO LCD Panel P420IVN01.0 42.0 inch tft lcd display module | |
P420IVN01.0 About MOQ:
Low MOQ! We welcome 1pcs as sample order to test and check quality. Mixed samples are acceptable.
P420IVN01.0 Unit Price:
The prices we provided are based on the new and original parts. We can offer a discount according to your purchase order quantity.
P420IVN01.0 About Payment Terms:
1. You can pay for your purchase order by PayPal, T/T, Western Union, Ali-escrow or Cash.
2. The unit price we provided not included any shipping fees or payment charges.
3. We are not responsible for any import fees or customs taxes.
P420IVN01.0 Shipping and Package :
P420IVN01.0 About Shipment Terms:
1. We will pack and send your goods within 2-3 working days after we confirmed your payment. For quickly packing and sending, please let us know if you finished the payment.
2. We will inform you the lead time if we have to purchase from manufacturer.
3. We usually ship by DHL, UPS, TNT, FedEx, Aramex or EMS. It usually takes 3-7 days to arrive. Air cargo and sea shipping are also optional.
4. We are not responsible for any accidents, delays or other issues that are the responsibility of shipping service.
5. We need your shipping information including your name, address and phone number for shipping your parcel.
6.Tracking number will be shared with you when we got it from the logistics company.
P420IVN01.0 About Quality Warranty:
1. Our products are all original and new from manufacturer. It must be work if the model number is correct.
2. We offer 365 days warranty to our products.
P420IVN01.0 FAQ:
Q: Can You declare my order of P420IVN01.0 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of P420IVN01.0 ?
A: 90days warranty .
Q: Do you accept sample orders for P420IVN01.0 ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods of P420IVN01.0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
