Innolux Vertical Stripe 15.6 lcd pane N156HCA-GA3 30 pins LCD Laptop Screen
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Innolux |
| Model Number: | N156HCA-GA3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | N156HCA-GA3 | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 (FHD) 141PPI | Active Area: | 344.16 × 193.59 (H×V) |
| Outline Dim.: | 350.66 × 205.69 × 5.4 (H×V×D) | Luminance: | 400 Cd/m² (Typ.) |
| Color Depth: | 262K 72% NTSC | Designed For: | Laptop |
Product Description
Innolux Vertical Stripe 15.6 lcd pane N156HCA-GA3 30 pins LCD Laptop Screen
N156HCA-GA3 Product details :
| Innolux LCD SCREEN N156HCA-GA3 | |
| Manufacturer | Innolux |
| Model Name | N156HCA-GA3 |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 350.66 × 216.25 × 3.2 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 11/9 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 262K 72% NTSC |
| Backlight | 10S6P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Innolux Vertical Stripe 15.6 lcd pane N156HCA-GA3 30 pins LCD Laptop Screen | |
N156HCA-GA3 Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
N156HCA-GA3 Note:
Product prototype number of links and compatible model random delivery. If you have any special requirements you need to specify the type, please inform us before order. Thank you very much.
N156HCA-GA3 About the goods:
Receive delivery company products, please check whether the parcel in good face to face. If damaged packaging or product damage, please refuse and ask the photos to prove it. Photos are divided into two parts, divided into two parts. A customer himself as evidence, the other a
Courier company as a third party. Then when we received the Courier company send us the pictures of damaged products, we will find out is responsible for the damage to the product of the case. No third party evidence we can't pay for.
N156HCA-GA3 About the shipping:
The recipient must be full name or company name.We use Aliexpresss standard transport EMS DHL, fedex, etc. You can choose the next order. if you want to quickly get parcel. Recommend the use of DHL or by EMS, if you choose the DHL transport. Some remote address DHL needs additional remote address for service. Fees paid by the buyer. Customs clearance fee, if any, shall be borne by the buyers.
After completion of the payment, the goods will be sent 1-3 working days. (part of the product according to the inventory needs more days)
N156HCA-GA3 Purchase Notice:
1.Please pay attention to AliExpress messages we leave so that I can contact you in time to check the model and shipping.
2.We will arrange your package within 2-5 days.Once we shipped, we will update the tracking number for you so that you can know your package where it is going on.
3.Shipping does not include your local customs clearance,please consult your local customs for further information.
4.60 days warranty for our goods.If you have any questions, please contact us,we are happy to help you.
N156HCA-GA3 Attention:
1.As you konw return or exchange the goods will take a long time.In order not to make mistake , make sure compare the products are the same as your laptop screen please.Check the screen size, resolution and interface type.
2. Or you can send me your laptop model such as ""Asus gl552vw"" and screen model name such as ""B156HTN03.8"" then we will check it for you as soon as possible.Send me pictures of your laptop model and screen name will be better.
3. We are looking forward to doing more business with you if you would like to order many items. We can give you the best price. Anyway if you have any problem, please feel free to contact us anytime.Because of jet lag we will reply you within 12 hours.
N156HCA-GA3 FAQ :
Q: How to make payment of N156HCA-GA3 ?
A: We accept T/T , Paypal , western union .
Q: If I place order now,when will you ship the goods of N156HCA-GA3 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How can I trace my order of N156HCA-GA3 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my order of N156HCA-GA3 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
N156HCA-GA3 Shipping and Package :
