BOE Vertical Stripe 15.6 lcd pane NV156FHM-N52 1920*1080 LCD SCREEN
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | BOE |
| Model Number: | NV156FHM-N52 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NV156FHM-N52 | Screen Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 141PPI | Display Area: | 344.16 × 193.59 (H×V) |
| Outline Size: | 350.66 × 205.84 × 4.6 (H×V×D) | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Display Colors: | 1.07B 72% NTSC | Used For: | Laptop |
Product Description
BOE Vertical Stripe 15.6 lcd pane NV156FHM-N52 1920*1080 LCD SCREEN
NV156FHM-N52 Product details :
| BOE LCD SCREEN NV156FHM-N52 | |
| Manufacturer | BOE |
| Model Name | NV156FHM-N52 |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 350.66 × 205.84 × 4.6 (H×V×D) |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1200 : 1 (Min.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 1.07B 72% NTSC |
| Backlight | 11S4P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Bent, T≤3.0mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| BOE Vertical Stripe 15.6 lcd pane NV156FHM-N52 1920*1080 LCD SCREEN | |
NV156FHM-N52 Helpful Information:
- We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
- Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.
- Please confirm it with us before buying if you need 100% new products only.
- If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.
NV156FHM-N52 Shipping:
1. We will test them strictly before shipping.
2. We will ship it within 3 working days after we get the order.
3. The delivery time normally will be 7 to 50 days, which will be different for different countries. You can choose AliExpress Standard Shipping,It is faster than others.
4. * United States / United Kingdom / Australia may take 7-30 working days.
5. * Canada may take 7-35 working days.
6. * France / Spain / Germany may take 7-30 working days.
7. * Eastern Europe may take 16-30 working days.
8. * Italy / Brazil / South America may take 30-50 working days.
9. * Shipped by DHL Express: 7-12 working days (you need to pay extra fee).
NV156FHM-N52 Warranty and Return:
1. We offer warranty for all of our products.
2. Buyers bear the shipping cost for returning defective or non-defective item to us.
3. Return items should be in good condition same as we sent, not damaged.
4. Returned items are subject to approval by us, it should be in original box as we sent.
5. Physically damaged items received should be reported within 2 days.
6. All NON-Seller Mistake returns, there is 15% re-stocking fees and shipping and handling charges are NON-refundable. (E.g. you boughtwrong item)
NV156FHM-N52 FAQ :
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: When will my order NV156FHM-N52 ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you declared low value for my order NV156FHM-N52 when shipping?
A: Yes, We can do it for you if you need.
Q: What happen if the lcd panel NV156FHM-N52 I received can't work ?
A: Our lcd display NV156FHM-N52 tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
NV156FHM-N52 Shipping and Package :
