Innolux Vertical Stripe 15.6 LCD Panel N156HCA-EBB 1920*1080 LCD Screen Display Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Innolux |
| Model Number: | N156HCA-EBB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | N156HCA-EBB | Screen Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 141PPI | Display Area: | 350.66 × 216.25 × 3.2 (H×V×D) |
| Outline Size: | 359.5 × 223.8 × 3.2 (H×V×D) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Display Colors: | 262K 45% NTSC | Used For: | Laptop |
| High Light: | Innolux 15.6 lcd panel,15.6 lcd panel N156HCA-EBB,1920*1080 LCD Screen Display Panel |
||
Product Description
Innolux vertical stripe 15.6 lcd panel N156HCA-EBB 1920*1080 LCD Screen Display Panel
N156HCA-EBB Product details :
| Innolux LCD SCREEN N156HCA-EBB | |
| Manufacturer |
Innolux |
| Model Name | N156HCA-EBB |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 350.66 × 216.25 × 3.2 (H×V×D) |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 220 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14/11 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 262K 45% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , Connector 30 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Innolux vertical stripe 15.6 lcd panel N156HCA-EBB 1920*1080 LCD Screen Display Panel | |
N156HCA-EBB Helpful Information:
- We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
- Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.
- Please confirm it with us before buying if you need 100% new products only.
- If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.
N156HCA-EBB Shipping:
1. We will test them strictly before shipping.
2. We will ship it within 3 working days after we get the order.
3. The delivery time normally will be 7 to 50 days, which will be different for different countries. You can choose AliExpress Standard Shipping,It is faster than others.
4. * United States / United Kingdom / Australia may take 7-30 working days.
5. * Canada may take 7-35 working days.
6. * France / Spain / Germany may take 7-30 working days.
7. * Eastern Europe may take 16-30 working days.
8. * Italy / Brazil / South America may take 30-50 working days.
9. * Shipped by DHL Express: 7-12 working days (you need to pay extra fee).
N156HCA-EBB Warranty Terms:
1. Satisfaction is guaranteed. If you are not completely satisfied with your purchase, you may return it for a refund or exchange it for a replacement. We only require that you contact us within 14 days of receiving your item and return it in the same condition it was received.
2. Returns will not be accepted if you happen to purchase the wrong item by mistake. So, please pay close attention to our picture and if possible compare it with your original part before purchasing.
3. For all returns, the buyer is responsible for paying the cost of the item’s return shipping.
N156HCA-EBB Warranty :
1, We take 12 months warranty from the shipping date , no matter what quality problem it's .
2, Pls keep in touch with us , if you have any problems pls contact us immediately , we will help you to solve the problem ASAP. .
N156HCA-EBB FAQ :
Q: How do you ship my goods N156HCA-EBB ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: How long is the warranty of Innolux N156HCA-EBB ?
A: 90 days warranty .
Q: How can I trace my order of N156HCA-EBB ?
A: we will give you tracking number then you can trace your order form website.
Q: Can you give me a discount if I need a large quantity of N156HCA-EBB ?
A: Of course!If you make a large order, we will give you a discount.
N156HCA-EBB Shipping and Package :
