Innolux 15.6" LCD Panel N156HCA-EAB 1920(RGB)×1080 Vertical Stripe 141PPI Laptop LCD Screen
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | BOE |
| Model Number: | N156HCA-EAB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | N156HCA-EAB (CMN15E7) | Panel Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 141PPI | Display Area: | 344.16(W)×193.59(H) Mm |
| Outline Size: | 350.66(W)×216.25(H)×3.2(D) Mm | Display Mode: | AAS, Normally Black, Transmissive |
| Shape Style: | Slim (PCBA Flat, T≤3.2mm) | Application: | Laptop |
Product Description
Innolux 15.6" LCD Panel N156HCA-EAB 1920(RGB)×1080 Vertical Stripe 141PPI Laptop LCD Screen
N156HCA-EAB (CMN15E7) Product details :
| Innolux LCD SCREEN N156HCA-EAB | |
| Manufacturer | Innolux |
| Model Name | N156HCA-EAB |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 350.66 × 216.25 × 3.2 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14/11 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 16.7M 45% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Innolux 15.6" LCD Panel N156HCA-EAB 1920(RGB)×1080 Vertical Stripe 141PPI Laptop LCD Screen | |
N156HCA-EAB (CMN15E7) Before order:
Before the order, please confirm whether your machine model matching with this LCD screen, if not sure, please contact us
N156HCA-EAB (CMN15E7) After payment:
After your payment please leave your monitor name and screen model ASAP.Once we got it we ship to you soon.We have to personally confirm your bought is correct screen model.
N156HCA-EAB (CMN15E7) Shipping and Package :
N156HCA-EAB (CMN15E7) Delivery customs
1. We can ship to Worldwide except the listed exclusions countries .
2. Any import tax charge or fee at destination country is buyer's responsibility, pls note it. Also the buyer need to pay remote fees if the deliver address is remote area in DHL/UPS/TNT or Fedex's (express shipping) systerm.Please leave a message in the order if you have any request for the declared amount.
3. You will be notified once the shipment has been made.The packages are safe with signature- required. if None sign for the package, it will be return ,please pick it up in your local post office. .
4. We offer shipping discount for DHL shipping.Please contact with us.
5.Due to the epidemic or holidays, the logistics time limit is not stable. Some channels may be suspended at any time or some channels warehouses have a large backlog of goods. We would like to choose which logistics is more stable, fast and safe at certain times for buyer. Such as buyer choose DHL, we may ship by the same level express like TNT, Fedex or UPS.If you need to specify logistics, leave a message online or note in the order
N156HCA-EAB (CMN15E7) Return & Replacement/Exchange policy:
1.If you have found any problems about our item after you tested it , pls contact us and we will reply ASAP.
2.Items can be returned for exchange within 10 days counting from the day you receive merchandise. Goods must be unworn and in original packaging.
3.Items returned will be tested by our technician, if it is true,we will refund or replace the defective merchandise,if not, the return policy will be unavailable for the buyer.
N156HCA-EAB (CMN15E7) FAQ :
Q: Can You declare my order of N156HCA-EAB (CMN15E7) to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of N156HCA-EAB (CMN15E7) ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goodsN156HCA-EAB (CMN15E7) ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of N156HCA-EAB (CMN15E7) via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How to make payment of N156HCA-EAB (CMN15E7) ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90days warranty .
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
