12.1 inch 82ppi lcd screen LTM12C275A 800×600 LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Toshiba Matsushita |
| Model Number: | LTM12C275A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LTM12C275A | Diagonal Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)×600 (SVGA) 82PPI | Active Area: | 246 × 184.5 (H×V) |
| Outline Dim.: | 290(H)×220(V) ×15(D) Mm | Color Depth: | 262K |
| Weight: | 840g (Typ.) | Designed For: | Industrial |
Product Description
12.1 inch 82ppi lcd screen LTM12C275A 800×600 LCD Display
LTM12C275A Product details :
| TOSHIBA LCD Screen LTM12C275A | |
| Brand | TOSHIBA |
| Model | LTM12C275A |
| Diagonal Size | 12.1 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×600 [SVGA] 82PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 246(H)×184.5(V) mm |
| Outline Dim. | 290(H)×220(V) ×15(D) mm |
| Bezel Area | 249.0(H)×187.5(V) mm |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 250:1 (Typ.) (TM) |
| Response Time | 50/50 (Max.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K |
| Light Source | CCFL [2 pcs] , 25K hours , W/O Driver |
| Weight | 840g (Typ.) |
| Designed For | Industrial |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 6-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.)(VDD) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| 12.1 inch 82ppi lcd screen LTM12C275A 800×600 LCD Display | |
LTM12C275A Helpful Information:
- We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
- Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition.
- Please confirm it with us before buying if you need 100% new products only.
- If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.
LTM12C275A About Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
LTM12C275A Delivery time is approx:
United States / United Kingdom / Australia 7-14 working days.
Canada 7-25 working days.
France / Spain / Germany may take 7-20 working days.
Eastern Europe may take up to 16-30 working days.
Italy / Brazil / South America may take up to 30-50 working days.
Shipped by DHL Express (Need 3-6 working days to arrive)
LTM12C275A Payment:
1.We can accept T/T and Western Union and Money order, the best way is direct order payment .you can choose your convenient payment terms. If you want other payment terms, please let us know before you order.
2.Full payment must be made within 7 days after placing your order, or the order will be invalid or cancelled by the system.
3.Make sure that you have completed all the detailed information like contact person, address, post code and telephone number when filling in your buyer’s information.
LTM12C275A Friendly Reminder :
- Installation guide is not included,We are not responsible for any damage caused by the installation of this accessory, make sure you understand how to install before ordering.
- Special skills and techniques required for proper installation. We recommend you process your repairment with an assistance of a qualified technician.
- Please make sure you understand disassembly procedure before purchase.It is strongly recommended that customers test the product before installation.
LTM12C275A Return:
All returns must be informed before returning.
The Buyer is ought to notify the seller of all returned items within 7 days after receiving the package. We reserve the right refusing any requirement that informs the seller longer than 7 days.
Exchange due to buyer wrong part ordered, buyer needs to pay 2-ways shipping fee.
Return items must have all original packaging and in good condition.
Return postage and insurance charge is non-refundable for refund or new shipment.
Shipping fees are non-refundable.
LTM12C275A FAQ:
Q: Can I pay my order of LTM12C275A via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: If I place order now,when will you ship the goods of LTM12C275A ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How can I trace my order of LTM12C275A ?
A: we will give you tracking number then you can trace your order from website.
LTM12C275A Shippment & Packing
