Industrial LCD Panel Display

12.1 inch 82ppi lcd screen LTA121B860F LCD display for industrial control

All Category

Floor Standing Digital Signage

12.1 inch 82ppi lcd screen LTA121B860F LCD display for industrial control

Brand Name:	Toshiba Matsushita
Model Number:	LTA121B860F
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LTA121B860F

Screen Size:

12.1 Inch

Pixel Number:

800(RGB)×600 (SVGA) 82PPI

Active Area(mm):

246 × 184.5 (H×V)

Outline(mm):

278.3 × 209 × 11 (H×V×D)

Bezel Area(mm):

249.0 × 187.5 (H×V)

Mass:

680g (Typ.)

Used For:

Industrial

Signal Type:

Parallel RGB (1 Ch, 6-bit) , Connector 32 Pins

Voltage Supply:

3.3V (Typ.)

Supply Ability:

100000 Unit/Units per Month

Product Description

12.1 inch 82ppi lcd screen LTA121B860F LCD display for industrial control

LTA121B860F Product details :

Toshiba Matsushita LCD SCREEN LTA121B860F
Brand	Toshiba Matsushita
Model	LTA121B860F
Diagonal Size	12.1 inch
Type	a-Si TFT-LCD , LCM
Pixel Format	800(RGB)×600 (SVGA) 82PPI
Configuration	RGB Vertical Stripe
Active Area	246 × 184.5 (H×V)
Outline Dim.	278.3 × 209 × 11 (H×V×D)
Bezel Area	249.0 × 187.5 (H×V)
Treatment	Hard coating
Luminance	380 cd/m² (Typ.)
Contrast Ratio	500 : 1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	30 (Typ.)(Tr+Td) ms
Viewing Angle	80/80/60/60 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K
Light Source	2 pcs CCFL , 12K hours , No Driver
Weight	680g (Typ.)
Designed For	Industrial
Frame Rate	60Hz
Touch Panel	No touch
Interface Type	Parallel RGB (1 ch, 6-bit) , 32 pins Connector
Power Supply	3.3V (Typ.)
Environment	Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 65 °C
12.1 inch 82ppi lcd screen LTA121B860F LCD display for industrial control

LTA121B860F About the quality:

All of our product will be testing before shipping . So you can be assured the quality of our products .

However, lf you found any problem after received the goods , Please feel free contact to our saleman .

We will be willing to deal with your problem at the first time .

LTA121B860F Our services:

Fast delivery

90days warranty

original,High quality

Full tested before shipping.

We mainly sell Industrial LCD panels and touch screens , providing information and technical consultation for all kinds of LCD screens and touch screens, Wehave many parts in stock ,such as the brand for

LTA121B860F Shippment & Packing

12.1 inch 82ppi lcd screen LTA121B860F LCD display for industrial control 0

LTA121B860F SHIPMENT:

Delivery time: 3-10 days for sample

Package: standard export packing or customized packing as your request.Professional goods shipping forwarder.

LTA121B860F Return/Refund Police:

1.We provide different warranty for different products.

2. Please inform us within 7 days if you receive any defective goods from us. The returned items has to be its original condition to qualify for a refund or replacement.

LTA121B860F FAQ:

Q: If I place order now,when will you ship the goods of LTA121B860F ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can You declare my order of LTA121B860F to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can I pay my order of LTA121B860F via credit card ?

A: Yes!you can use your credit card through your Paypal account.
