12.1 inch 82ppi lcd screen LQ121S1DC71 800(RGB)×600 lcd display panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ121S1DC71 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LQ121S1DC71 | Panel Size: | 12.1" |
|---|---|---|---|
| Resolution: | 800(RGB)×600, SVGA, 82PPI | Display Area: | 246(W)×184.5(H) Mm |
| Outline Size: | 265(W)×205(H)×10(D) Mm | Brightness: | 800 Cd/m² (Typ.) |
| Panel Weight: | 550g (Max.) | Application: | Industrial |
| Signal Interface: | Parallel RGB (1 Ch, 6-bit) , 30 Pins Connector | Input Voltage: | 3.3V (Typ.) |
Product Description
12.1 inch 82ppi lcd screen LQ121S1DC71 800(RGB)×600 lcd display panel
LQ121S1DC71 Product details :
| Sharp LCD Screen LQ121S1DC71 | |
| Panel Brand | Sharp |
| Panel Model | LQ121S1DC71 |
| screen size | 12.1inches |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA, 82PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 246(W)×184.5(H) mm |
| physical dimension | 265(W)×205(H)×10(D) mm |
| Surface | Clear, Hard coating (3H) |
| Brightness | 800 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Optical mode | TN, Normally White, Transmissive |
| Number of colors | 262K , 50% NTSC |
| Response time | 30 (Typ.)(Tr+Td) ms |
| View Direction | 6 o'clock |
| Backlight type | 8S3P WLED , 50K hours, without driver |
| Designed For | Industrial |
| Touch Screen | Without |
| screen weight | 550g (Max.) |
| signal system | Parallel RGB (1 ch, 6-bit) , 30 pins , terminal |
| Supply voltage | 3.3V (Typ.) |
| maximum rating | Working: -15 ~ 75 °C ; Storage: -30 ~ 75 °C |
| 12.1 inch LQ121S1DC71 lcd screen Display new and original | |
LQ121S1DC71 Our Advantage:
1. High quality
2. Competitive price
3.Secure payment
4. Fast delivery
5. Excellent service
6. More than 10 year experience
If you have any inquiry, feel free to contact us.
LQ121S1DC71 Payment:
We accept T/T (Bank Transfer), Western Union, Paypal,Credit card, Visa, Escrow
We offer flexible payment terms including COD(NET) terms to good customers.
LQ121S1DC71 Shippment & Packing
LQ121S1DC71 Shipping:
All orders will be shipped within 3-4 business days from HK after the payment is cleared.
As long as you are not in remote countries and cities, our preferred shipping method is DHL. We want to provide you with the best service.
all shipment will be with tracking number.
LQ121S1DC71 About the warranty and return:
1.We accept returns for replacement or refund within 5 days after receipt of item(s).Items MUST be in their original condition, not worn or altered.
2. We do not reimburse the return shipping charge.Refunds will be for the original price paid, and will be issued within 7 business days after receipt of the return.
LQ121S1DC71 FAQ:
Q: Can you give me a discount if I need a large quantity of LQ121S1DC71 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods LQ121S1DC71?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can You declare my order of LQ121S1DC71 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of LQ121S1DC71 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
