12.1 inch 82ppi lcd screen LQ121S1DG42 800(RGB)×600 lcd display
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ121S1DG42 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LQ121S1DG42 | Diagonal Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)×600 [SVGA] 82PPI | Active Area: | 246(H)×184.5(V) Mm |
| Outline Dim.: | 276(H)×209(V)×11(D) Mm | Bezel Area: | 249.0(H)×187.5(V) Mm |
| Weight: | 660g (Max.) | Designed For: | Industrial |
Product Description
12.1 inch 82ppi lcd screen LQ121S1DG42 800(RGB)×600 lcd display
LQ121S1DG42 Product details :
| SHARP LCD SCREEN LQ121S1DG42 | |
| manufacturer | SHARP |
| Model Name | LQ121S1DG42 |
| screen size | 12.1inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 800(RGB)×600 SVGA 82PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 246 × 184.5 (H×V) mm |
| physical area | 276 × 209 × 11 (H×V×D) mm |
| open area | 249.0 × 187.5 (H×V) mm |
| Contrast | Matte, Hard coating (3H) |
| Display | 370 cd/m² (Typ.) |
| contrast | 450:1 (Typ.) (Transmission) |
| Viewing angle | 70/70/50/60 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| Number of color | 262K , 50% NTSC |
| Reaction time | 10/25 (Typ.)(Tr/Td) |
| Backlight type | 2 pcs CCFL,50K hours, |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Panel weight | 660g (Max.) |
| Signal | 41 pins LVDS (1 ch, 6-bit) , terminal |
| drive voltage | 3.3/5.0V (Typ.) |
| working | Storage temperature: -30 ~ 80 °C Operating temperature: -30 ~ 80 °C |
| 12.1 inch 82ppi lcd screen LQ121S1DG42 800(RGB)×600 lcd display | |
LQ121S1DG42 Our service:
1. We ship within 2~5 days as soon as possible；
2. We support sample service, MOQ = 1；
3. We have strong R & D and production capabilities and have sufficient inventory；
4. We will innovate and develop new products every month；
5. We are OEM / ODM；
6. We are at your service 24 hours. Product quality issues can be returned at any time；
7. We ship your products with the fastest and best logistics；
LQ121S1DG42 About Payment Terms:
1. You can pay for your purchase order by PayPal, T/T, Western Union or Cash.
2. The unit price we provided not included any shipping fees or payment charges.
3. We are not responsible for any import fees or customs taxes.
LQ121S1DG42 Shippment & Packing
LQ121S1DG42 Shipment:
1. Worldwide shipping.
2. Order will be shipped within 1-3 days after receiving your money
3. Major express partners: DHL,UPS,EMS,Fedex.
4. We are not responsible for any import fees,remote area charges,taxes or other Customs fees.
LQ121S1DG42 Quality:
lf the goods you received is damaged,wrong or defective,please contact us first for a new replacement or refund. the returned package must be packed well You also need to leave a message into the returned box for the order information.contact information and return reason,so that we can know where it is from.
LQ121S1DG42 FAQ:
Q: If I place order now,when will you ship the goods of LQ121S1DG42 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of LQ121S1DG42 ?
A: Of course!sample order is welcome !
Q: How to make payment of LQ121S1DG42 ?
A: We accept T/T , Paypal , western union .
Q: Can I pay my order of LQ121S1DG42 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
