12.1 inch 82ppi lcd screen LQ121S1DG61 LCD Panel substitution for Sharp
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ121S1DG61 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LQ121S1DG61 | Diagonal Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)×600 [SVGA] 82PPI | Active Area: | 246(H)×184.5(V) Mm |
| Outline Dim.: | 276(H)×209(V)×11(D) Mm | Bezel Area: | 249.0(H)×187.5(V) Mm |
| Weight: | 800g (Max.) | Designed For: | Industrial |
Product Description
12.1 inch 82ppi lcd screen LQ121S1DG61 LCD Panel substitution for Sharp
LQ121S1DG61 Product details :
| SHARP LCD SCREEN LQ121S1DG61 | |
| manufacturer | SHARP |
| Model Name | LQ121S1DG61 |
| screen size | 12.1inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 800(RGB)×600 SVGA 82PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 246 × 184.5 (H×V) mm |
| physical area | 276 × 209 × 11 (H×V×D) mm |
| open area | 249.0 × 187.5 (H×V) mm |
| Contrast | Matte, Hard coating (3H) |
| Display | 450 cd/m² (Typ.) |
| contrast | 600:1 (Typ.) (Transmission) |
| Viewing angle | 70/70/50/60 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| Number of color | 262K , 44% NTSC |
| Reaction time | 10/25 (Typ.)(Tr/Td) |
| Backlight type | 2 pcs CCFL,50K hours, |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Panel weight | 800g (Max.) |
| Signal | 41 pins LVDS (1 ch, 6-bit) , terminal |
| drive voltage | 3.3/5.0V (Typ.) |
| working | Storage temperature: -30 ~ 80 °C Operating temperature: -30 ~ 80 °C |
| 12.1 inch 82ppi lcd screen LQ121S1DG61 LCD Panel substitution for Sharp | |
LQ121S1DG61 Our Services:
1. Reply your inquiry in 24 working hours.
2. Expertized staffs reply all your questions with good English communication.
3. Customized design is available. Can provide you video brochure template to make design .
4. Unique solution can be provided to customers by our well-trained and professional staff.
5. After-sell services and technology support is available.
6. Your satisfaction is our pursuit. Only provide high quality video brochure and video module .
7. Warranty time : Video module: 2years, video greeting card: 1 year
LQ121S1DG61 Payment:
We usually accept the payment methods include T/T, Western Union and Trade Assurance. 50-100% deposit in advance and balance before shipping upon the payment amount. Buyer can choose which payment ways that you accept.
LQ121S1DG61 Shippment & Packing
LQ121S1DG61 About Shipment Terms:
1. We will pack and send your goods 1-3 working days after we confirmed your payment. For quickly packing and sending, please let us know if you finished the payment.
2. We need your shipping information including your name, address and phone number for shipping your parcel.
3. Tracking number will be shared with you when we got it from the logistics company.
LQ121S1DG61 Warranty and Refund:
1.All products will be tested strictly before shipping to make sure they are 100% working well.
2.Please also test them within 3-5 days after received. BUT DO NOT INSTALL before testing(ONLY connect LCD to mainboard for testing).If LCD damaged after Installation ,order Non-Refundable and WARRANTY VOID.
3.We provide 6-month warranty for all our products,but the original labels marked by us must not be removed,nor any of the parts have been used or damaged deliberately.
LQ121S1DG61 FAQ:
Q: Can you give me a discount if I need a large quantity of LQ121S1DG61 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of LQ121S1DG61 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: If I place order now,when will you ship the goods of LQ121S1DG61 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How to make payment of LQ121S1DG61 ?
A: We accept T/T , Paypal , western union .
